FG45TU-10 Komatsu LPG Forklift Specs & Dimensions (2021 - 2026)

Nominal load at COG: 4.5t – Centre of gravity: 600mm – Standard tyres: 2x/2 – Transmission type: HY – Weight: 6.8t – Total width: …

Nominal load at COG: 4.5t – Centre of gravity: 600mm – Standard tyres: 2x/2 – Transmission type: HY – Weight: 6.8t – Total width: 1450mm

Komatsu is the manufacturer of the FG45TU-10 LPG forklift. The production years for this model are (2021 - 2026). Find here detailed specs for FG45TU-10 LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Komatsu.

LPG Forklifts Komatsu FG45TU-10

Visit Komatsu live at

Technical specs - FG45TU-10 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
4.5 t
Centre of gravity
600 mm
Standard tyres
2x/2
Transmission type
HY
Weight
6.8 t
Total width
1450 mm
Construction height
2250 mm
Turning radius
2.82 m
Lifting height
3 m
Travel speed with / without load
23/24 km/h
Hoisting with / without load
0.44/044 m/s
Lowering with load
0.5 m/s
max. climbing ability
26 %
Model series
FG
Engine manuf.
Nissan
Engine type
EBT-TB45-1A
Engine power
69 kW
Displacement
4.478 l
Revolutions at max torque
1600 rpm
Max. torque
272 Nm
No. of cylinders
6

More technical details, like: dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
