33L-9A Hyundai LPG Forklift Specs & Dimensions (2019 - 2026)

Nominal load at COG: 3.3t – Centre of gravity: 500mm – Standard tyres: P 2x/2 – Weight: 4.395t – Total width: 1228mm – Constructio…

Nominal load at COG: 3.3t – Centre of gravity: 500mm – Standard tyres: P 2x/2 – Weight: 4.395t – Total width: 1228mm – Construction height: 2260mm

Hyundai is the manufacturer of the 33L-9A LPG forklift. The production years for this model are (2019 - 2026). Find here detailed specs for 33L-9A LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Hyundai.

LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A
LPG Forklifts Hyundai 33L-9A

Visit Hyundai live at

Technical specs - 33L-9A Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.3 t
Centre of gravity
500 mm
Standard tyres
P 2x/2
Weight
4.395 t
Total width
1228 mm
Construction height
2260 mm
Turning radius
2.463 m
Lifting height
3.305 m
Travel speed with / without load
18.9 km/h
Hoisting with / without load
0.46/0.48 m/s
Lowering with load
0.5 m/s
max. climbing ability
26 %
Model series
9
Engine manuf.
HMC
Engine type
L4KB
Engine power
44.1 kW
Displacement
2.359 l
Revolutions at max torque
2300 rpm
Max. torque
19/1800 Nm
No. of cylinders
4
Emission level
V

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
