20 L 7 Hyundai LPG Forklift Specs & Dimensions (2008 - 2011)

Model rating
8,00 / 10

Nominal load at COG: 2t – Centre of gravity: 500mm – Standard tyres: L4 – Transmission type: W – Weight: 3.476t – Turning radius: …

Nominal load at COG: 2t – Centre of gravity: 500mm – Standard tyres: L4 – Transmission type: W – Weight: 3.476t – Turning radius: 2.05m

Hyundai is the manufacturer of the 20 L 7 LPG forklift. The production years for this model are (2008 - 2011). Find here detailed specs for 20 L 7 LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Hyundai.

LPG Forklifts Hyundai 20 L 7

Visit Hyundai live at

Technical specs - 20 L 7 Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
2 t
Centre of gravity
500 mm
Standard tyres
L4
Transmission type
W
Weight
3.476 t
Turning radius
2.05 m
Lifting height
3.525 m
Travel speed with / without load
20.7 km/h
Hoisting with / without load
0.65/0.68 m/s
Lowering with load
0.5 m/s
max. climbing ability
31 %
Model series
7
Engine manuf.
Hyundai
Engine type
HMC Beta
Engine power
37 kW

More technical details, like: total width, construction height, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
