GC35S-9 BCS Doosan LPG Forklift Specs & Dimensions (2022 - 2026)

Nominal load at COG: 3.629t – Centre of gravity: 610mm – Standard tyres: 22 x 9 x16/18 x 7 x 12.2 – Weight: 5.81t – Total width: 1…

Nominal load at COG: 3.629t – Centre of gravity: 610mm – Standard tyres: 22 x 9 x16/18 x 7 x 12.2 – Weight: 5.81t – Total width: 1270mm – Construction height: 2155mm

Doosan is the manufacturer of the GC35S-9 BCS LPG forklift. The production years for this model are (2022 - 2026). Find here detailed specs for GC35S-9 BCS LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Doosan.

LPG Forklifts Doosan GC35S-9 BCS

Visit Doosan live at

Technical specs - GC35S-9 BCS Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.629 t
Centre of gravity
610 mm
Standard tyres
22 x 9 x16/18 x 7 x 12.2
Weight
5.81 t
Total width
1270 mm
Construction height
2155 mm
Turning radius
2.104 m
Lifting height
2.88 m
Travel speed with / without load
16.4/16.9 km/h
Hoisting with / without load
0.61/0.64 m/s
Lowering with load
0.51 m/s
Model series
GC 9
Engine manuf.
Kubota
Engine type
WG3800
Engine power
69 kW
Displacement
3.769 l
Revolutions at max torque
1800 rpm
Max. torque
290 Nm
No. of cylinders
4

More technical details, like: transmission type, max. climbing ability, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
