G33P-5 Doosan LPG Forklift Specs & Dimensions (2017 - 2021)

Nominal load at COG: 3.25t – Centre of gravity: 500mm – Transmission type: W – Total width: 1197mm – Construction height: 2183mm –…

Nominal load at COG: 3.25t – Centre of gravity: 500mm – Transmission type: W – Total width: 1197mm – Construction height: 2183mm – Turning radius: 2.395m

Doosan is the manufacturer of the G33P-5 LPG forklift. The production years for this model are (2017 - 2021). Find here detailed specs for G33P-5 LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Doosan.

LPG Forklifts Doosan G33P-5

Visit Doosan live at

Technical specs - G33P-5 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.25 t
Centre of gravity
500 mm
Transmission type
W
Total width
1197 mm
Construction height
2183 mm
Turning radius
2.395 m
Travel speed with / without load
20 km/h
Hoisting with / without load
0.57 m/s
Model series
5
Engine manuf.
Hyundai
Engine type
G424P(E)
Engine power
48.9 kW
Displacement
2.351 l
Revolutions at max torque
2000 rpm
Max. torque
183.2 Nm

More technical details, like: standard tyres, weight, lifting height, lowering with load, max. climbing ability, dimension lxwxh, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
