    Technical specs - C5 1050-40 Crown

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Nominal load at COG 1.814 t
    Standard tyres Front: 7.00 - 12 / Rear: 6.00 - 9
    Centre of gravity 610 mm
    Weight 3.908 t
    Total width 1194 mm
    Construction height 2184 mm
    Turning radius 2.222 m
    Lifting height 7.47 m
    Travel speed with / without load 19.6 / 19.6 km/h
    Hoisting with / without load 0.65 / 0.66 m/s
    Lowering with load 0.47 m/s
    max. climbing ability 28.5 %
    Engine manuf. N/A
    Engine type N/A
    Engine power 44 kW
    Engine power 59 HP
    Displacement 2.4 l
    Revolutions at max torque 1400 rpm
    Max. torque 169 Nm
    No. of cylinders 4
    Transmission type ###
    Dimension lxwxh ###
    Cylinder bore x stroke ###
    Weight ###
    Emission level ###

    L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
