GP35N Caterpillar LPG Forklift Specs & Dimensions (2025 - 2026)

Nominal load at COG: 3.5t – Centre of gravity: 500mm – Standard tyres: Front:  250-15 -12PR / Rear:  6.50-10-10PR – Weight: 4.63t …

Nominal load at COG: 3.5t – Centre of gravity: 500mm – Standard tyres: Front:  250-15 -12PR / Rear:  6.50-10-10PR – Weight: 4.63t – Total width: 1690mm – Construction height: 2300mm

Caterpillar is the manufacturer of the GP35N LPG forklift. The production years for this model are (2025 - 2026). Find here detailed specs for GP35N LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Caterpillar.

LPG Forklifts Caterpillar GP35N

Technical specs - GP35N Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.5 t
Centre of gravity
500 mm
Standard tyres
Front:  250-15 -12PR / Rear:  6.50-10-10PR
Weight
4.63 t
Total width
1690 mm
Construction height
2300 mm
Turning radius
2.44 m
Lifting height
3.3 m
Travel speed with / without load
16,5/18 km/h
Hoisting with / without load
0.43/0.44 m/s
Lowering with load
0,42/0,4 m/s
max. climbing ability
26/48 %
Model series
GP
Engine manuf.
N/A
Engine type
GK25E
Engine power
46.9 kW
Displacement
2.488 l
Revolutions at max torque
2700 rpm
Max. torque
188/1600 Nm
No. of cylinders
4

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
