PT 182 Palazzani PT 182 Specifications & Technical Data (2013—2021)

The Palazzani PT 182 is a wheel loader manufactured from 2013 to 2021. It has a weight of 9 tons and a transport length of 6.71 me…

The Palazzani PT 182 is a wheel loader manufactured from 2013 to 2021. It has a weight of 9 tons and a transport length of 6.71 meters. The bucket capacity is 1.4 cubic meters, with a bucket width of 2.25 meters. The maximum discharge height is 4.8 meters, and it has a travel speed of 40 km/h. The transport width and height are both 2.25 and 2.86 meters, respectively. The turning radius outside is 5.165 meters. Special equipment includes a quick hitch mechanism and telescopic capabilities.

PT 182

Years of manufacture: 2013—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PT 182 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9 t

Standard tyres: 15.5x25 R

Bucket width: 2.25 m

Bucket capacity: 1.4 m³

Bucket capacity min.: 1.4 m³

Steering mode: KL

Transport length: 6.71 m

Transport width: 2.25 m

Transport height: 2.86 m

Travel speed: 40 km/h

Max. discharge height: 4.8 m

Turning radius outside: 5.165 m

Model series: PT

Engine manuf.: JCB

Engine type: 444 TA 4F

Engine power: 93 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

Emission level: Tier 4 f

More technical details, like: bucket capacity max., lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

PT 182 Palazzani Specification for Europe (EN)

Palazzani PT 182 FAQ

When was the Palazzani PT 182 manufactured?

The Palazzani PT 182 was manufactured from 2013 to 2021.

How much does the Palazzani PT 182 weigh?

The Palazzani PT 182 weighs 9 tons.

What are the transport dimensions of the Palazzani PT 182 wheel loader?

The Palazzani PT 182 has a transport length of 6.71 meters, a transport width of 2.25 meters, and a transport height of 2.86 meters.

What is the travel speed of the Palazzani PT 182 wheel loader?

The Palazzani PT 182 has a travel speed of 40 km/h.

What are the undercarriage specifications of the Palazzani PT 182 wheel loader?

The Palazzani PT 182 wheel loader is equipped with standard tyres sized 15.5x25 R.

What are the maneuverability specifications of the Palazzani PT 182 wheel loader?

The Palazzani PT 182 has an articulated-frame steering system and an outside turning radius of 5.165 meters.

What is the maximum discharge height of the Palazzani PT 182?

The Palazzani PT 182 has a maximum discharge height of 4.8 meters.

What are the specifications of the primary work tool bucket on the Palazzani PT 182?

The Palazzani PT 182 has a bucket with a capacity of 1.4 cubic meters and a width of 2.25 meters.
