L 9 Ljungby L 9 Specifications & Technical Data (2010—2018)

The Ljungby L 9 is a wheel loader manufactured from 2010 to 2018. It has a weight of 10.5 tons and a transport length of 6.95 mete…

The Ljungby L 9 is a wheel loader manufactured from 2010 to 2018. It has a weight of 10.5 tons and a transport length of 6.95 meters. The bucket capacity is 1.6 cubic meters, with a bucket width of 2.62 meters. The maximum discharge height is 3.985 meters. It has a transport width of 2.31 meters and a transport height of 3.205 meters. The lifting force is 95 kN, and the turning radius outside is 5.63 meters. The minimum bucket capacity is 1.6 cubic meters.

L 9

Years of manufacture: 2010—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 9 Ljungby

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.5 t

Standard tyres: 17.5 R25

Bucket width: 2.62 m

Bucket capacity: 1.6 m³

Bucket capacity min.: 1.6 m³

Steering mode: KL

Transport length: 6.95 m

Transport width: 2.31 m

Transport height: 3.205 m

Max. discharge height: 3.985 m

Turning radius outside: 5.63 m

Lifting force: 95 kN

Engine manuf.: Mercedes-Benz

Engine type: OM904 LAT

Engine power: 130 kW

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Ljungby L 9 FAQ

When was the Ljungby L 9 manufactured?

The Ljungby L 9 was manufactured from 2010 to 2018.

How much does the Ljungby L 9 wheel loader weigh?

The Ljungby L 9 wheel loader weighs 10.5 tons.

What are the transport dimensions of the Ljungby L 9 wheel loader?

The Ljungby L 9 has a transport length of 6.95 meters, a transport width of 2.31 meters, and a transport height of 3.21 meters.

What are the undercarriage tyre specifications of the Ljungby L 9 wheel loader?

The Ljungby L 9 wheel loader is equipped with standard tyres sized 17.5 R25.

What are the maneuverability specifications of the Ljungby L 9 wheel loader?

The Ljungby L 9 wheel loader has an articulated-frame steering system and an outside turning radius of 5.63 meters.

What is the lifting force, as the power rating, of the Ljungby L 9 wheel loader?

The Ljungby L 9 wheel loader has a lifting force of 95 kN.

What is the material handling capacity of the Ljungby L 9 in terms of discharge height?

The Ljungby L 9 has a maximum discharge height of 3.99 meters.

What are the specifications of the primary work tool bucket on the Ljungby L 9 wheel loader?

The Ljungby L 9 wheel loader has a bucket with a capacity of 1.6 cubic meters, a minimum bucket capacity of 1.6 cubic meters, and a bucket width of 2.62 meters.

How much is a Ljungby L 9 Wheel loader (2010u20132018) worth?

The residual value of the Ljungby L 9 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
