411 HT JCB 411 HT Specifications & Technical Data (2016—2021)

The JCB 411 HT is a wheel loader manufactured from 2016 to 2021. It has a weight of 8.78 tons and a transport length of 6.23 meter…

The JCB 411 HT is a wheel loader manufactured from 2016 to 2021. It has a weight of 8.78 tons and a transport length of 6.23 meters. The bucket capacity is 1.2 cubic meters, with a bucket width of 2.25 meters. The maximum discharge height is 2.78 meters, and it has a travel speed of 40 km/h. The transport width is 2.2 meters, and the transport height is 3.06 meters. It has a lifting force of 73.2 kN and a turning radius outside of 5.35 meters. Special equipment includes air conditioning and a quick hitch hydraulic mechanism.

Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT

Visit JCB live at

Technical specs - 411 HT JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.78 t
Standard tyres
15.5 R25 XHA
Bucket width
2.25 m
Bucket capacity
1.2 m³
Bucket capacity min.
1.2 m³
Steering mode
KL
Transport length
6.23 m
Transport width
2.2 m
Transport height
3.06 m
Travel speed
40 km/h
Max. discharge height
2.78 m
Turning radius outside
5.35 m
Lifting force
73.2 kN
Engine manuf.
JCB
Engine type
EcoMax
Engine power
81 kW
Displacement
4.4 l
Max. torque
516 Nm
No. of cylinders
4
Emission level
Tier 4 Final/ IV

More technical details, like: bucket capacity max., model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

JCB 411 HT FAQ

When was the JCB 411 HT manufactured?

The JCB 411 HT was manufactured from 2016 to 2021.

How much does the JCB 411 HT weigh?

The JCB 411 HT weighs 8.78 tons.

What are the transport dimensions of the JCB 411 HT wheel loader?

The JCB 411 HT has a transport length of 6.23 meters, a transport width of 2.2 meters, and a transport height of 3.06 meters.

What is the travel speed of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader is equipped with standard tyres sized 15.5 R25 XHA.

What are the maneuverability specifications of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has an articulated-frame steering system and an outside turning radius of 5.35 meters.

What is the lifting force of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a lifting force of 73.2 kN.

What is the maximum discharge height of the JCB 411 HT?

The JCB 411 HT has a maximum discharge height of 2.78 meters.

What are the specifications of the bucket on the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a bucket with a capacity of 1.2 cubic meters, a minimum bucket capacity of 1.2 cubic meters, and a bucket width of 2.25 meters.

How much is a JCB 411 HT Wheel loader (2016u20132021) worth?

The residual value of the JCB 411 HT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
