AS 900 tele Mecalac AS 900 tele Specifications & Technical Data (2012—2014)

The Mecalac AS 900 tele is a wheel loader manufactured by Mecalac from 2012 to 2014. It has a weight of 7.2 tons and a transport l…

The Mecalac AS 900 tele is a wheel loader manufactured by Mecalac from 2012 to 2014. It has a weight of 7.2 tons and a transport length of 6.27 meters. The bucket capacity is 0.9 cubic meters with a width of 1.95 meters. The maximum discharge height is 4.1 meters and it has a travel speed of 20 km/h. The transport width is 2.06 meters and the transport height is 2.83 meters. It has a lifting force of 37 kN and a turning radius outside of 3.7 meters. The bucket capacity ranges from a minimum of 0.9 cubic meters to a maximum of 1.5 cubic meters. It is equipped with special features such as a quick hitch hydr., swing loader, and telescopic capabilities.

Wheel Loaders Mecalac AS 900 tele
Wheel Loaders Mecalac AS 900 tele
Wheel Loaders Mecalac AS 900 tele
Wheel Loaders Mecalac AS 900 tele

Technical specs - AS 900 tele Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.2 t
Standard tyres
16/17-20
Bucket width
1.95 m
Bucket capacity
0.9 m³
Bucket capacity min.
0.9 m³
Bucket capacity max.
1.5 m³
Steering mode
AL
Transport length
6.27 m
Transport width
2.06 m
Transport height
2.83 m
Travel speed
20 km/h
Max. discharge height
4.1 m
Turning radius outside
3.7 m
Lifting force
37 kN
Model series
AS

More technical details, like: engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
Yes
telescopic
Yes
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Mecalac AS 900 tele FAQ

When was the Mecalac AS 900 tele manufactured?

The Mecalac AS 900 tele was manufactured from 2012 to 2014.

How much does the Mecalac AS 900 tele weigh?

The Mecalac AS 900 tele weighs 7.2 tons.

What are the transport dimensions of the Mecalac AS 900 tele wheel loader?

The Mecalac AS 900 tele wheel loader has a transport length of 6.27 meters, a transport width of 2.06 meters, and a transport height of 2.83 meters.

What is the travel speed of the Mecalac AS 900 tele wheel loader?

The Mecalac AS 900 tele wheel loader has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac AS 900 tele wheel loader?

The Mecalac AS 900 tele wheel loader is equipped with standard tyres sized 16/17-20.

What are the maneuverability specifications of the Mecalac AS 900 tele wheel loader?

The Mecalac AS 900 tele features all-wheel steering and has an outside turning radius of 3.7 meters.

What is the lifting force of the Mecalac AS 900 tele wheel loader?

The Mecalac AS 900 tele wheel loader has a lifting force of 37 kN.

What is the maximum discharge height of the Mecalac AS 900 tele?

The Mecalac AS 900 tele has a maximum discharge height of 4.1 meters.

What are the specifications of the bucket on the Mecalac AS 900 tele wheel loader?

The Mecalac AS 900 tele wheel loader has a bucket with a capacity ranging from 0.9 to 1.5 cubic meters and a width of 1.95 meters.

How much is a Mecalac AS 900 tele Wheel loader (2012u20132014) worth?

The residual value of the Mecalac AS 900 tele depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
