1101 c Wacker Neuson 1101 c Specifications & Technical Data (2008—2018)

The Wacker Neuson 1101 c Skid Steer Loader, manufactured from 2008 to 2018, weighs 4.4 tons and has a transport length of 3.535 me…

The Wacker Neuson 1101 c Skid Steer Loader, manufactured from 2008 to 2018, weighs 4.4 tons and has a transport length of 3.535 meters. It is equipped with a bucket capacity of 0.45 cubic meters and a bucket width of 2.03 meters. The maximum discharge height is 2.38 meters, and it can travel at a speed of 12 km/h. The transport width is 1.98 meters, and the transport height is 2.065 meters. The track width is 450 mm, and it has a rated operating capacity of 1150 kg.

Visit Wacker Neuson live at

1101 c

Years of manufacture: 2008—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - 1101 c Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.4 t

Rated operating capacity: 1150 kg

Track width: 450 mm

Bucket width: 2.03 m

Bucket capacity: 0.45 m³

Driver protection: KbR

Steering mode: PL

Transport length: 3.535 m

Transport width: 1.98 m

Transport height: 2.065 m

Travel speed: 12 km/h

Max. discharge height: 2.38 m

Engine manuf.: Deutz

Engine type: TD2011

Engine power: 63 kW

Displacement: 3.619 l

Revolutions at max torque: 2500 rpm

More technical details, like: standard tyres, lifting force, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, engine manufacturer, engine model, emission rating, number of cylinders, aspiration, rated speed, engine output - gross, transmission type, drive method, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, hydraulic power, hydraulic power - option, pump flow, pump flow - option, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter: No
LPG motor: No
Burglar proof system: No

Download datasheets (PDF)

Wacker Neuson 1101 c FAQ

When was the Wacker Neuson 1101 c manufactured?

The Wacker Neuson 1101 c was manufactured from 2008 to 2018.

How much does the Wacker Neuson 1101 c weigh?

The Wacker Neuson 1101 c weighs 4.4 tons.

What are the transport dimensions of the Wacker Neuson 1101 c skid steer loader?

The Wacker Neuson 1101 c has a transport length of 3.54 meters, a transport width of 1.98 meters, and a transport height of 2.07 meters.

What is the travel speed of the Wacker Neuson 1101 c skid steer loader?

The Wacker Neuson 1101 c has a travel speed of 12 km/h.

What is the track width of the Wacker Neuson 1101 c skid steer loader?

The Wacker Neuson 1101 c skid steer loader has a track width of 450 mm.

What is the steering mode of the Wacker Neuson 1101 c skid steer loader?

The Wacker Neuson 1101 c has tank steering.

What is the material handling capacity of the Wacker Neuson 1101 c skid steer loader?

The Wacker Neuson 1101 c has a rated operating capacity of 1150 kg and a maximum discharge height of 2.38 meters.

What are the specifications of the primary work tool bucket on the Wacker Neuson 1101 c?

The primary work tool bucket of the Wacker Neuson 1101 c has a capacity of 0.45 cubic meters and a width of 2.03 meters.

What operator safety features does the Wacker Neuson 1101 c skid steer loader have?

The Wacker Neuson 1101 c skid steer loader is equipped with a cabin that includes ROPS for driver protection.

How much is a Wacker Neuson 1101 c Skid steer loader (2008u20132018) worth?

The residual value of the Wacker Neuson 1101 c depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
