SSL 707 TCM SSL 707 Specifications & Technical Data (2024—2026)
.jpg)
.jpg)
Technical specs - SSL 707 TCM
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Rated operating capacity
- 580 kg
- Standard tyres
- 10-16.5-6PR
- Bucket width
- 1.54 m
- Bucket capacity
- 0.31 m³
- Transport length
- 3.09 m
- Transport width
- 1.535 m
- Transport height
- 1.94 m
- Travel speed
- 12 km/h
- Lifting force
- 22.5 kN
- Engine manuf.
- Kubota
- Engine type
- V2403-M
- Engine power
- 33.5 kW
- Displacement
- 2.43 l
- Revolutions at max torque
- 1600 rpm
- Max. torque
- 156.4 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 60 x 715 mm
More technical details, like: weight, track width, driver protection, steering mode, max. discharge height, model series, dimension lxwxh, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
