N 30 Neumeier N 30 Specifications & Technical Data (2007—2012)

The Neumeier N 30 is a skid steer loader manufactured by Neumeier from 2007 to 2012. It has a weight of 2.45 tons and a transport …

The Neumeier N 30 is a skid steer loader manufactured by Neumeier from 2007 to 2012. It has a weight of 2.45 tons and a transport length of 2.869 meters. The bucket capacity is 0.21 cubic meters with a bucket width of 1.47 meters. The maximum discharge height is 1.8 meters and the transport width is also 1.47 meters. It has a rated operating capacity of 850 kilograms.

Skid Steer Loaders Neumeier N 30

Technical specs - N 30 Neumeier

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.45 t
Rated operating capacity
850 kg
Standard tyres
8.5x15
Bucket width
1.47 m
Bucket capacity
0.21 m³
Driver protection
KbR
Steering mode
PL
Transport length
2.869 m
Transport width
1.47 m
Travel speed
10.5 km/h
Max. discharge height
1.8 m
Model series
N
Engine manuf.
Perkins
Engine type
HN 33
Engine power
24.6 kW
Revolutions at max torque
2650 rpm

More technical details, like: track width, transport height, lifting force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine model...

More technical details, like: track width, transport height, lifting force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine model, rated speed, engine output - net, transmission type, tyre size, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, height to hinge pin, dump height - maximum, reach - max dump height, fuel tank, tipping load, operating capacity, speed - maximum, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Neumeier N 30 FAQ

When was the Neumeier N 30 manufactured?

The Neumeier N 30 was manufactured from 2007 to 2012.

How much does the Neumeier N 30 skid steer loader weigh?

The Neumeier N 30 skid steer loader weighs 2.45 tons.

What are the transport dimensions of the Neumeier N 30 skid steer loader?

The Neumeier N 30 has a transport length of 2.87 meters and a transport width of 1.47 meters.

What is the travel speed of the Neumeier N 30 skid steer loader?

The Neumeier N 30 skid steer loader has a travel speed of 10.5 km/h.

What is the standard tyre size of the Neumeier N 30 skid steer loader?

The Neumeier N 30 skid steer loader has standard tyres sized 8.5x15.

What is the steering mode of the Neumeier N 30 skid steer loader?

The Neumeier N 30 skid steer loader has a steering mode of tank steering.

What is the material handling capacity of the Neumeier N 30 skid steer loader?

The Neumeier N 30 skid steer loader has a rated operating capacity of 850 kg and a maximum discharge height of 1.8 meters.

What are the bucket specifications of the Neumeier N 30 skid steer loader?

The Neumeier N 30 skid steer loader has a bucket capacity of 0.21 cubic meters and a bucket width of 1.47 meters.

What operator safety and support features does the Neumeier N 30 skid steer loader have?

The Neumeier N 30 skid steer loader features a cabin with ROPS for driver protection.
