90 John Deere Construction 90 Specifications & Technical Data (1978—2021)

The John Deere Construction 90 is a skid steer loader that has been manufactured from 1978 to 2021. It has a weight of 1.281 tons …

The John Deere Construction 90 is a skid steer loader that has been manufactured from 1978 to 2021. It has a weight of 1.281 tons and a transport length of 2.591 meters. The bucket capacity is 0.25 cubic meters with a width of 1.194 meters. The maximum discharge height is 2.489 meters. It has a travel speed of 8 km/h and a transport width of 1.156 meters. The transport height is 1.88 meters.

Skid Steer Loaders John Deere Construction 90

Technical specs - 90 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.281 t
Standard tyres
8.50-15
Bucket width
1.194 m
Bucket capacity
0.25 m³
Driver protection
KbR
Transport length
2.591 m
Transport width
1.156 m
Transport height
1.88 m
Travel speed
8 km/h
Max. discharge height
2.489 m
Engine manuf.
Onan
Engine type
NHC
Engine power
17.15 kW
Displacement
0.983 l
Max. torque
55.6 Nm
No. of cylinders
2

More technical details, like: rated operating capacity, track width, steering mode, lifting force, model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

John Deere Construction 90 FAQ

When was the John Deere Construction 90 manufactured?

The John Deere Construction 90 was manufactured from 1978 to 2021.

How much does the John Deere Construction 90 skid steer loader weigh?

The John Deere Construction 90 skid steer loader weighs 1.28 tons.

What are the transport dimensions of the John Deere Construction 90 skid steer loader?

The John Deere Construction 90 skid steer loader has a transport length of 2.59 meters, a transport width of 1.16 meters, and a transport height of 1.88 meters.

What is the travel speed of the John Deere Construction 90 skid steer loader?

The John Deere Construction 90 skid steer loader has a travel speed of 8 km/h.

What are the undercarriage tyre specifications of the John Deere Construction 90 skid steer loader?

The John Deere Construction 90 skid steer loader is equipped with standard tyres sized 8.50-15.

What is the maximum discharge height of the John Deere Construction 90?

The John Deere Construction 90 has a maximum discharge height of 2.49 meters.

What are the specifications of the primary work tool bucket on the John Deere Construction 90 skid steer loader?

The primary work tool bucket of the John Deere Construction 90 has a capacity of 0.25 cubic meters and a width of 1.19 meters.

What operator safety and support features does the John Deere Construction 90 skid steer loader have?

The John Deere Construction 90 skid steer loader features a cabin with ROPS for driver protection.
