313 John Deere Construction 313 Specifications & Technical Data (2007—2021)

The John Deere Construction 313 Skid Steer Loader, manufactured from 2007 to 2021, weighs 2.338 tons and has a transport length of…

The John Deere Construction 313 Skid Steer Loader, manufactured from 2007 to 2021, weighs 2.338 tons and has a transport length of 3.14 meters. It features a bucket width of 1.47 meters and a maximum discharge height of 2.77 meters. With a travel speed of 10.9 km/h, it has a transport width of 1.5 meters and a transport height of 1.96 meters.

Skid Steer Loaders John Deere Construction 313

Technical specs - 313 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.338 t
Standard tyres
10x16.5 8 PR
Bucket width
1.47 m
Driver protection
KbR
Transport length
3.14 m
Transport width
1.5 m
Transport height
1.96 m
Travel speed
10.9 km/h
Max. discharge height
2.77 m
Model series
300
Engine manuf.
John Deere
Engine type
4024T
Engine power
33.5 kW
Displacement
2.4 l
Max. torque
188 Nm
No. of cylinders
4
Emission level
EPA interm Tier 4

More technical details, like: rated operating capacity, track width, bucket capacity, steering mode, lifting force, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

John Deere Construction 313 FAQ

When was the John Deere Construction 313 manufactured?

The John Deere Construction 313 was manufactured from 2007 to 2021.

How much does the John Deere Construction 313 skid steer loader weigh?

The John Deere Construction 313 skid steer loader weighs 2.34 tons.

What are the transport dimensions of the John Deere Construction 313 skid steer loader?

The John Deere Construction 313 has a transport length of 3.14 meters, a transport width of 1.5 meters, and a transport height of 1.96 meters.

What is the travel speed of the John Deere Construction 313 skid steer loader?

The John Deere Construction 313 has a travel speed of 10.9 km/h.

What are the undercarriage specifications of the John Deere Construction 313 skid steer loader?

The John Deere Construction 313 skid steer loader is equipped with standard tyres sized 10x16.5 8 PR.

What is the maximum discharge height of the John Deere Construction 313?

The John Deere Construction 313 has a maximum discharge height of 2.77 meters.

What is the bucket width of the John Deere Construction 313 skid steer loader?

The bucket width of the John Deere Construction 313 skid steer loader is 1.47 meters.

What operator safety and support features does the John Deere Construction 313 skid steer loader have?

The John Deere Construction 313 skid steer loader features a cabin with ROPS for driver protection.

How much is a John Deere Construction 313 Skid steer loader (2007u20132021) worth?

The residual value of the John Deere Construction 313 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
