SL 7810 DXT Dual Gehl SL 7810 DXT Dual Specifications & Technical Data (2007—2011)

The Gehl SL 7810 DXT Dual is a skid steer loader manufactured by Gehl from 2007 to 2011. It has a weight of 4.72 tons and a transp…

The Gehl SL 7810 DXT Dual is a skid steer loader manufactured by Gehl from 2007 to 2011. It has a weight of 4.72 tons and a transport length of 4.089 meters. The bucket capacity is 0.89 cubic meters, with a width of 2.14 meters. The transport width and height are both 2.057 meters. The rated operating capacity of this machine is 1805 kilograms.

Skid Steer Loaders Gehl SL 7810 DXT Dual

Technical specs - SL 7810 DXT Dual Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.72 t
Rated operating capacity
1805 kg
Standard tyres
14.00x17.5
Bucket width
2.14 m
Bucket capacity
0.89 m³
Driver protection
KbR
Steering mode
PL
Transport length
4.089 m
Transport width
2.057 m
Transport height
2.057 m
Model series
SL
Engine manuf.
Cummins
Engine type
B4.5T 99C
Engine power
74 kW
Displacement
4.5 l
Revolutions at max torque
2200 rpm

More technical details, like: track width, travel speed, max. discharge height, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer...

More technical details, like: track width, travel speed, max. discharge height, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - bucket, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Gehl SL 7810 DXT Dual FAQ

When was the Gehl SL 7810 DXT Dual manufactured?

The Gehl SL 7810 DXT Dual was manufactured from 2007 to 2011.

How much does the Gehl SL 7810 DXT Dual weigh?

The Gehl SL 7810 DXT Dual weighs 4.72 tons.

What are the transport dimensions of the Gehl SL 7810 DXT Dual skid steer loader?

The Gehl SL 7810 DXT Dual has a transport length of 4.09 meters, a transport width of 2.06 meters, and a transport height of 2.06 meters.

What are the undercarriage tyre specifications of the Gehl SL 7810 DXT Dual skid steer loader?

The Gehl SL 7810 DXT Dual skid steer loader is equipped with standard tyres sized 14.00x17.5.

What type of steering system does the Gehl SL 7810 DXT Dual skid steer loader use?

The Gehl SL 7810 DXT Dual skid steer loader uses a tank steering system.

What is the material handling capacity of the Gehl SL 7810 DXT Dual skid steer loader?

The Gehl SL 7810 DXT Dual skid steer loader has a rated operating capacity of 1805 kg.

What are the specifications of the primary work tool bucket on the Gehl SL 7810 DXT Dual skid steer loader?

The Gehl SL 7810 DXT Dual skid steer loader has a bucket with a capacity of 0.89 cubic meters and a width of 2.14 meters.

What operator safety and support features does the Gehl SL 7810 DXT Dual have?

The Gehl SL 7810 DXT Dual is equipped with a cabin that includes ROPS for driver protection.
