ESK 190 Eurocomach ESK 190 Specifications & Technical Data (2016—2021)

The Eurocomach ESK 190 is a skid steer loader manufactured from 2016 to 2021. It has a weight of 4.35 tons and a transport length …

The Eurocomach ESK 190 is a skid steer loader manufactured from 2016 to 2021. It has a weight of 4.35 tons and a transport length of 3.95 meters. The bucket capacity is 0.55 cubic meters with a width of 1.86 meters. The maximum discharge height is 2.42 meters. The transport width is 1.86 meters and the transport height is 2.18 meters. The rated operating capacity is 1450 kilograms. It is equipped with a burglar proof system.

Skid Steer Loaders Eurocomach ESK 190

Technical specs - ESK 190 Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.35 t
Rated operating capacity
1450 kg
Standard tyres
12-16.5
Bucket width
1.86 m
Bucket capacity
0.55 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.95 m
Transport width
1.86 m
Transport height
2.18 m
Max. discharge height
2.42 m
Model series
CWL
Engine manuf.
Yanmar
Engine type
4TNV98T
Engine power
63.9 kW
Displacement
3.319 l
Revolutions at max torque
1850 rpm
Max. torque
296.1 Nm
No. of cylinders
4
Emission level
III A

More technical details, like: track width, travel speed, lifting force, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
Yes

Download datasheets (PDF)

Eurocomach ESK 190 FAQ

When was the Eurocomach ESK 190 manufactured?

The Eurocomach ESK 190 was manufactured from 2016 to 2021.

How much does the Eurocomach ESK 190 weigh?

The Eurocomach ESK 190 weighs 4.35 tons.

What are the transport dimensions of the Eurocomach ESK 190 skid steer loader?

The Eurocomach ESK 190 has a transport length of 3.95 meters, a transport width of 1.86 meters, and a transport height of 2.18 meters.

What are the undercarriage tyre specifications of the Eurocomach ESK 190?

The Eurocomach ESK 190 is equipped with standard tyres sized 12-16.5.

What is the steering mode of the Eurocomach ESK 190?

The Eurocomach ESK 190 has an all-wheel steering mode.

What is the material handling capacity of the Eurocomach ESK 190 skid steer loader?

The Eurocomach ESK 190 has a rated operating capacity of 1450 kg and a maximum discharge height of 2.42 meters.

What are the specifications of the primary work tool on the Eurocomach ESK 190?

The primary work tool of the Eurocomach ESK 190 has a bucket capacity of 0.55 cubic meters and a bucket width of 1.86 meters.

What operator safety and support features does the Eurocomach ESK 190 have?

The Eurocomach ESK 190 is equipped with a cabin that includes ROPS for driver protection.

How much is a Eurocomach ESK 190 Skid steer loader (2016u20132021) worth?

The residual value of the Eurocomach ESK 190 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
