SR150 Case SR150 Specifications & Technical Data (2010—2026)

The Case SR150 is a skid steer loader manufactured by Case since 2010. It has a weight of 2.4 tons and a transport length of 2.44 …

The Case SR150 is a skid steer loader manufactured by Case since 2010. It has a weight of 2.4 tons and a transport length of 2.44 meters. The travel speed of this construction machine is 12 km/h, with a transport width of 1.52 meters and a transport height of 3.6 meters. The rated operating capacity is 680.4 kilograms.

Skid Steer Loaders Case SR150

Technical specs - SR150 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.4 t
Rated operating capacity
680.4 kg
Standard tyres
10X16.5
Transport length
2.44 m
Transport width
1.52 m
Transport height
3.6 m
Travel speed
12 km/h
Engine manuf.
ISM
Engine type
N844T
Engine power
40 kW
Displacement
2 l
Max. torque
148 Nm
No. of cylinders
4

More technical details, like: track width, bucket width, bucket capacity, driver protection, steering mode, max. discharge height, lifting force, model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case SR150 FAQ

When was the Case SR150 manufactured?

The Case SR150 was first produced in 2010.

How much does the Case SR150 skid steer loader weigh?

The Case SR150 skid steer loader weighs 2.4 tons.

What are the transport dimensions of the Case SR150 skid steer loader?

The Case SR150 skid steer loader has a transport length of 2.44 meters, a transport width of 1.52 meters, and a transport height of 3.6 meters.

What is the travel speed of the Case SR150 skid steer loader?

The Case SR150 skid steer loader has a travel speed of 12 km/h.

What is the standard tyre size of the Case SR150 skid steer loader?

The Case SR150 skid steer loader has standard tyres sized 10X16.5.

What is the material handling capacity of the Case SR150 skid steer loader?

The Case SR150 skid steer loader has a rated operating capacity of 680.4 kg.

How much is a Case SR150 Skid steer loader (2010u20132025) worth?

The residual value of the Case SR150 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
