90XT Case 90XT Specifications & Technical Data (1997—2014)
Technical specs - 90XT Case
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.994 t
- Rated operating capacity
- 1088.64 kg
- Standard tyres
- 10X16.5
- Transport length
- 2.68 m
- Transport width
- 1.64 m
- Transport height
- 3.82 m
- Travel speed
- 12 km/h
- Model series
- XT
- Engine manuf.
- Case
- Engine type
- 4T 390
- Engine power
- 63 kW
- Displacement
- 3.92 l
- Max. torque
- 317 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 102x120 mm
More technical details, like: track width, bucket width, bucket capacity, driver protection, steering mode, max. discharge height, lifting force, dimension lxwxh, revolutions at max torque, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
