410 S 3 Case 410 S 3 Specifications & Technical Data (2008—2012)

The Case 410 S 3 is a skid steer loader manufactured by Case from 2008 to 2012. It has a weight of 2.46 tons and a transport lengt…

The Case 410 S 3 is a skid steer loader manufactured by Case from 2008 to 2012. It has a weight of 2.46 tons and a transport length of 3.13 meters. The bucket capacity is 0.47 cubic meters, with a bucket width of 1.82 meters. The maximum discharge height is 0.6 meters. The transport width is 1.5 meters, and the transport height is 3.84 meters. The lifting force is 20.7 kilonewtons, and the rated operating capacity is 680 kilograms.

Skid Steer Loaders Case 410 S 3

Technical specs - 410 S 3 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.46 t
Rated operating capacity
680 kg
Standard tyres
10.00x16.5
Bucket width
1.82 m
Bucket capacity
0.47 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.13 m
Transport width
1.5 m
Transport height
3.84 m
Travel speed
9.7 km/h
Max. discharge height
0.6 m
Lifting force
20.7 kN
Model series
S
Engine manuf.
Case
Engine type
422T-M3
Engine power
45 kW
Displacement
2.21 l
Revolutions at max torque
2900 rpm

More technical details, like: track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed...

More technical details, like: track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - bucket, lift capacity, pump type, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 410 S 3 FAQ

When was the Case 410 S 3 manufactured?

The Case 410 S 3 was manufactured from 2008 to 2012.

How much does the Case 410 S 3 skid steer loader weigh?

The Case 410 S 3 skid steer loader weighs 2.46 tons.

What are the transport dimensions of the Case 410 S 3 skid steer loader?

The Case 410 S 3 skid steer loader has a transport length of 3.13 meters, a transport width of 1.5 meters, and a transport height of 3.84 meters.

What is the travel speed of the Case 410 S 3 skid steer loader?

The Case 410 S 3 skid steer loader has a travel speed of 9.7 km/h.

What are the undercarriage specifications of the Case 410 S 3 skid steer loader?

The Case 410 S 3 skid steer loader is equipped with standard tyres sized 10.00x16.5.

What is the steering mode of the Case 410 S 3 skid steer loader?

The Case 410 S 3 skid steer loader has all-wheel steering.

What is the lifting force of the Case 410 S 3 skid steer loader, given that no power rating data is available?

The Case 410 S 3 skid steer loader has a lifting force of 20.7 kN. No power rating data is provided in the source.

What is the material handling capacity of the Case 410 S 3 skid steer loader?

The Case 410 S 3 skid steer loader has a rated operating capacity of 680 kg and a maximum discharge height of 0.6 meters.

What are the specifications of the primary work tool bucket on the Case 410 S 3 skid steer loader?

The primary work tool bucket on the Case 410 S 3 has a capacity of 0.47 cubic meters and a width of 1.82 meters.

What operator safety and support features does the Case 410 S 3 have?

The Case 410 S 3 is equipped with a cabin that includes ROPS for driver protection.

How much is a Case 410 S 3 Skid steer loader (2008u20132012) worth?

The residual value of the Case 410 S 3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
