410 Case 410 Specifications & Technical Data (2006—2008)

The Case 410 is a skid steer loader manufactured by Case from 2006 to 2008. It has a weight of 2.49 tons and a bucket capacity of …

The Case 410 is a skid steer loader manufactured by Case from 2006 to 2008. It has a weight of 2.49 tons and a bucket capacity of 0.5 cubic meters. The maximum discharge height is 0.64 meters, and it has a travel speed of 11 km/h. The lifting force is 20.7 kilonewtons, and the track width is 1490 millimeters. The rated operating capacity is 680 kilograms.

Skid Steer Loaders Case 410

Technical specs - 410 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.49 t
Rated operating capacity
680 kg
Track width
1490 mm
Bucket capacity
0.5 m³
Driver protection
KbR
Travel speed
11 km/h
Max. discharge height
0.64 m
Lifting force
20.7 kN
Engine manuf.
Case
Engine type
422M2
Engine power
42 kW
Displacement
2.2 l

More technical details, like: standard tyres, bucket width, steering mode, transport length, transport width, transport height, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke...

More technical details, like: standard tyres, bucket width, steering mode, transport length, transport width, transport height, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - bucket, lift capacity, pump type, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 410 FAQ

When was the Case 410 skid steer loader manufactured?

The Case 410 skid steer loader was manufactured from 2006 to 2008.

How much does the Case 410 skid steer loader weigh?

The Case 410 skid steer loader weighs 2.49 tons.

What is the travel speed of the Case 410 skid steer loader?

The Case 410 skid steer loader has a travel speed of 11 km/h.

What is the track width of the Case 410 skid steer loader?

The Case 410 skid steer loader has a track width of 1490 mm.

What are the power ratings of the Case 410 skid steer loader?

There are no power rating specifications available for the Case 410 skid steer loader in the provided data.

What is the material handling capacity of the Case 410 skid steer loader?

The Case 410 skid steer loader has a rated operating capacity of 680 kg and a maximum discharge height of 0.64 meters.

What is the bucket capacity of the Case 410 skid steer loader?

The Case 410 skid steer loader has a bucket capacity of 0.5 cubic meters.

What operator safety and support features does the Case 410 skid steer loader have?

The Case 410 skid steer loader features a cabin with ROPS for driver protection.

How much is a Case 410 Skid steer loader (2006u20132008) worth?

The residual value of the Case 410 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
