40 XT Case 40 XT Specifications & Technical Data (2002—2005)

The Case 40 XT is a skid steer loader manufactured by Case from 2002 to 2005. It has a weight of 2.59 tons and a transport length …

The Case 40 XT is a skid steer loader manufactured by Case from 2002 to 2005. It has a weight of 2.59 tons and a transport length of 3.13 meters. The bucket capacity is 0.33 cubic meters, with a bucket width of 1.52 meters. The maximum discharge height is 2.27 meters. The transport width is 1.5 meters, and the transport height is 1.92 meters. The lifting force is 16.85 kilonewtons, and the rated operating capacity is 680 kilograms.

Skid Steer Loaders Case 40 XT
Skid Steer Loaders Case 40 XT
Skid Steer Loaders Case 40 XT
Skid Steer Loaders Case 40 XT
Skid Steer Loaders Case 40 XT
Skid Steer Loaders Case 40 XT

Technical specs - 40 XT Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.59 t
Rated operating capacity
680 kg
Standard tyres
10.00x16.5
Bucket width
1.52 m
Bucket capacity
0.33 m³
Driver protection
KbR
Transport length
3.13 m
Transport width
1.5 m
Transport height
1.92 m
Travel speed
11.0 km/h
Max. discharge height
2.27 m
Lifting force
16.85 kN
Model series
XT
Engine manuf.
Case
Engine type
4-390
Engine power
42 kW
Displacement
3.917 l
Revolutions at max torque
2000 rpm

More technical details, like: track width, steering mode, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 40 XT FAQ

When was the Case 40 XT manufactured?

The Case 40 XT was manufactured from 2002 to 2005.

How much does the Case 40 XT skid steer loader weigh?

The Case 40 XT skid steer loader weighs 2.59 tons.

What are the transport dimensions of the Case 40 XT skid steer loader?

The Case 40 XT has a transport length of 3.13 meters, a transport width of 1.5 meters, and a transport height of 1.92 meters.

What is the travel speed of the Case 40 XT skid steer loader?

The Case 40 XT skid steer loader has a travel speed of 11 km/h.

What is the standard tyre size of the Case 40 XT skid steer loader?

The Case 40 XT skid steer loader has standard tyres sized 10.00x16.5.

What power rating information is available for the Case 40 XT skid steer loader?

No power rating information is provided for the Case 40 XT skid steer loader in the available data.

What is the material handling capacity of the Case 40 XT skid steer loader?

The Case 40 XT skid steer loader has a rated operating capacity of 680 kg and a maximum discharge height of 2.27 meters.

What are the specifications of the primary work tool on the Case 40 XT skid steer loader?

The primary work tool of the Case 40 XT skid steer loader has a bucket capacity of 0.33 cubic meters and a bucket width of 1.52 meters.

What operator safety and support features does the Case 40 XT skid steer loader have?

The Case 40 XT skid steer loader features a cabin with ROPS for driver protection.

How much is a Case 40 XT Skid steer loader (2002u20132005) worth?

The residual value of the Case 40 XT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
