1825 B Case 1825 B Specifications & Technical Data (1996—2003)

Model rating
7,12 / 10

The Case 1825 B is a skid steer loader manufactured by Case from 1996 to 2003. It has a weight of 1.46 tons and a transport length…

The Case 1825 B is a skid steer loader manufactured by Case from 1996 to 2003. It has a weight of 1.46 tons and a transport length of 2.77 meters. The bucket capacity is 0.2 cubic meters, with a bucket width of 1.24 meters. The maximum discharge height is 1.93 meters. The transport width is 1.2 meters, and the transport height is 1.78 meters. The lifting force is 7.7 kilonewtons, and the rated operating capacity is 400 kilograms.

Skid Steer Loaders Case 1825 B

Technical specs - 1825 B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.46 t
Rated operating capacity
400 kg
Standard tyres
27-8.50x15
Bucket width
1.24 m
Bucket capacity
0.2 m³
Driver protection
KbR
Transport length
2.77 m
Transport width
1.2 m
Transport height
1.78 m
Travel speed
8.7 km/h
Max. discharge height
1.93 m
Lifting force
7.7 kN
Model series
B
Engine manuf.
Kubota
Engine type
V1505B
Engine power
20 kW
Displacement
1.498 l
Revolutions at max torque
2400 rpm

More technical details, like: track width, steering mode, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 1825 B FAQ

When was the Case 1825 B skid steer loader manufactured?

The Case 1825 B skid steer loader was manufactured from 1996 to 2003.

How much does the Case 1825 B skid steer loader weigh?

The Case 1825 B skid steer loader weighs 1.46 tons.

What are the transport dimensions of the Case 1825 B skid steer loader?

The Case 1825 B skid steer loader has a transport length of 2.77 meters, a transport width of 1.2 meters, and a transport height of 1.78 meters.

What is the travel speed of the Case 1825 B skid steer loader?

The Case 1825 B skid steer loader has a travel speed of 8.7 km/h.

What are the standard tyres of the Case 1825 B skid steer loader?

The Case 1825 B skid steer loader is equipped with standard tyres sized 27-8.50x15.

What is the lifting force rating of the Case 1825 B skid steer loader?

The Case 1825 B skid steer loader has a lifting force of 7.7 kN.

What is the material handling capacity of the Case 1825 B skid steer loader?

The Case 1825 B skid steer loader has a rated operating capacity of 400 kg and a maximum discharge height of 1.93 meters.

What are the specifications of the primary work tool bucket on the Case 1825 B skid steer loader?

The primary work tool bucket of the Case 1825 B has a capacity of 0.2 cubic meters and a width of 1.24 meters.

What operator safety and support features does the Case 1825 B have?

The Case 1825 B is equipped with a cabin that includes ROPS for driver protection.

How much is a Case 1825 B Skid steer loader (1996u20132003) worth?

The residual value of the Case 1825 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
