T650 Bobcat T650 Specifications & Technical Data (2010—2017)

The Bobcat T650 is a skid steer loader manufactured by Bobcat from 2010 to 2017. It has a weight of 4.28 tons and a transport leng…

The Bobcat T650 is a skid steer loader manufactured by Bobcat from 2010 to 2017. It has a weight of 4.28 tons and a transport length of 3.47 meters. The bucket capacity is 1.13 cubic meters with a width of 1.88 meters. The maximum discharge height is 2.45 meters. The transport width is 1.85 meters and the transport height is 2.06 meters. The track width is 320 millimeters. It has a rated operating capacity of 1271 kilograms.

Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650
Skid Steer Loaders Bobcat T650

Visit Bobcat live at

Technical specs - T650 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.28 t
Rated operating capacity
1271 kg
Track width
320 mm
Bucket width
1.88 m
Bucket capacity
1.13 m³
Driver protection
KbR
Transport length
3.47 m
Transport width
1.85 m
Transport height
2.06 m
Travel speed
10.6 km/h
Max. discharge height
2.45 m
Model series
T
Engine manuf.
Kubota
Engine type
V3307DI-T-E
Engine power
55.4 kW
Displacement
3.331 l
Revolutions at max torque
1600 rpm
Emission level
III B

More technical details, like: standard tyres, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, undercarriage type, lift geometry, access, suspension seat, telematics available...

More technical details, like: standard tyres, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, undercarriage type, lift geometry, access, suspension seat, telematics available, security system available, engine manufacturer, engine model, emission rating, number of cylinders, aspiration, rated speed, engine output - gross, rated speed - torque, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, hydraulic power - option, pump flow, pump flow - option, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat T650 FAQ

When was the Bobcat T650 manufactured?

The Bobcat T650 was manufactured from 2010 to 2017.

How much does the Bobcat T650 weigh?

The Bobcat T650 weighs 4.28 tons.

What are the transport dimensions of the Bobcat T650 skid steer loader?

The Bobcat T650 has a transport length of 3.47 meters, a transport width of 1.85 meters, and a transport height of 2.06 meters.

What is the travel speed of the Bobcat T650 skid steer loader?

The Bobcat T650 has a travel speed of 10.6 km/h.

What is the track width of the Bobcat T650 skid steer loader?

The Bobcat T650 skid steer loader has a track width of 320 mm.

What is the material handling capacity of the Bobcat T650 skid steer loader?

The Bobcat T650 skid steer loader has a rated operating capacity of 1271 kilograms.

What are the specifications of the primary work tool bucket on the Bobcat T650?

The Bobcat T650's primary work tool bucket has a capacity of 1.13 cubic meters and a width of 1.88 meters.

What operator safety and support features does the Bobcat T650 have?

The Bobcat T650 is equipped with a cabin that includes ROPS (Roll Over Protective Structure) for driver protection.

How much is a Bobcat T650 Skid steer loader (2010u20132017) worth?

The residual value of the Bobcat T650 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
