T110 Bobcat T110 Specifications & Technical Data (2009—2018)

The Bobcat T110 is a skid steer loader manufactured by Bobcat from 2009 to 2018. It has a weight of 2.38 tons and a transport leng…

The Bobcat T110 is a skid steer loader manufactured by Bobcat from 2009 to 2018. It has a weight of 2.38 tons and a transport length of 2.972 meters. The bucket capacity is 0.45 cubic meters with a width of 1.27 meters. The maximum discharge height is 1.999 meters and it has a travel speed of 8.4 km/h. The transport width is 1.199 meters and the transport height is 1.882 meters. The lifting force is 1.559 kN and the track width is 320 mm. The rated operating capacity is 505 kg.

Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110
Skid Steer Loaders Bobcat T110

Visit Bobcat live at

Technical specs - T110 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.38 t
Rated operating capacity
505 kg
Track width
320 mm
Bucket width
1.27 m
Bucket capacity
0.45 m³
Driver protection
Kb
Transport length
2.972 m
Transport width
1.199 m
Transport height
1.882 m
Travel speed
8.4 km/h
Max. discharge height
1.999 m
Lifting force
1.559 kN
Model series
T
Engine manuf.
Kubota
Engine type
V2403-M-DI-E3
Engine power
31.2 kW
Displacement
2.434 l
Revolutions at max torque
1400 rpm
Max. torque
155.9 Nm
No. of cylinders
4

More technical details, like: standard tyres, steering mode, dimension lxwxh, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, security system available, engine manufacturer...

More technical details, like: standard tyres, steering mode, dimension lxwxh, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, security system available, engine manufacturer, engine model, emission rating, number of cylinders, aspiration, rated speed, engine output - gross, rated speed - torque, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, pump flow, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat T110 FAQ

When was the Bobcat T110 skid steer loader manufactured?

The Bobcat T110 skid steer loader was manufactured from 2009 to 2018.

How much does the Bobcat T110 skid steer loader weigh?

The Bobcat T110 skid steer loader weighs 2.38 tons.

What are the transport dimensions of the Bobcat T110 skid steer loader?

The Bobcat T110 has a transport length of 2.97 meters, a transport width of 1.2 meters, and a transport height of 1.88 meters.

What is the travel speed of the Bobcat T110 skid steer loader?

The Bobcat T110 has a travel speed of 8.4 km/h.

What is the track width of the Bobcat T110 skid steer loader?

The Bobcat T110 skid steer loader has a track width of 320 mm.

What is the lifting force of the Bobcat T110 skid steer loader?

The Bobcat T110 has a lifting force of 1.559 kN.

What is the material handling capacity of the Bobcat T110 skid steer loader?

The Bobcat T110 skid steer loader has a rated operating capacity of 505 kg and a maximum discharge height of 2 meters.

What are the specifications of the primary work tool bucket on the Bobcat T110?

The Bobcat T110's primary work tool bucket has a capacity of 0.45 cubic meters and a width of 1.27 meters.

What operator safety and support features does the Bobcat T110 have?

The Bobcat T110 has driver protection in the form of a cabin.

How much is a Bobcat T110 Skid steer loader (2009u20132018) worth?

The residual value of the Bobcat T110 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
