S450 Bobcat S450 Specifications & Technical Data (2017—2019)

The Bobcat S450 is a compact skid steer loader manufactured by Bobcat from 2017 to 2019. It has a weight of 2.36 tons and a transp…

The Bobcat S450 is a compact skid steer loader manufactured by Bobcat from 2017 to 2019. It has a weight of 2.36 tons and a transport length of 3.17 meters. The bucket capacity is 1.9406 cubic meters, with a width of 1.57 meters. The maximum discharge height is 2.16 meters. It has a travel speed of 14.8 km/h and a transport width of 1.49 meters. The transport height is 1.98 meters. The rated operating capacity is 608 kilograms.

Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450

Visit Bobcat live at

Technical specs - S450 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.36 t
Rated operating capacity
608 kg
Standard tyres
10 x 16.5. 12–ply.
Bucket width
1.57 m
Bucket capacity
1.9406 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.17 m
Transport width
1.49 m
Transport height
1.98 m
Travel speed
14.8 km/h
Max. discharge height
2.16 m
Model series
S
Engine manuf.
Kubota
Engine type
V2203-M-DI-E2B-BC-3
Engine power
36.4 kW
Displacement
2.196 l
Revolutions at max torque
1425 rpm
Max. torque
150 Nm
No. of cylinders
4
Emission level
III B

More technical details, like: track width, lifting force, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat S450 FAQ

When was the Bobcat S450 manufactured?

The Bobcat S450 was manufactured from 2017 to 2019.

How much does the Bobcat S450 skid steer loader weigh?

The Bobcat S450 skid steer loader weighs 2.36 tons.

What are the transport dimensions of the Bobcat S450 skid steer loader?

The Bobcat S450 has a transport length of 3.17 meters, a transport width of 1.49 meters, and a transport height of 1.98 meters.

What is the travel speed of the Bobcat S450 skid steer loader?

The Bobcat S450 skid steer loader has a travel speed of 14.8 km/h.

What are the undercarriage specifications of the Bobcat S450 skid steer loader?

The Bobcat S450 skid steer loader comes with standard tyres sized 10 x 16.5 with a 12u2013ply rating.

What is the steering mode of the Bobcat S450 skid steer loader?

The Bobcat S450 skid steer loader features all-wheel steering.

What is the material handling capacity of the Bobcat S450 skid steer loader?

The Bobcat S450 has a rated operating capacity of 608 kg and a maximum discharge height of 2.16 meters.

What are the specifications of the primary work tool bucket on the Bobcat S450?

The primary work tool bucket of the Bobcat S450 has a capacity of 1.94 cubic meters and a width of 1.57 meters.

What operator safety and support features does the Bobcat S450 have?

The Bobcat S450 is equipped with a cabin that includes ROPS for driver protection.

How much is a Bobcat S450 Skid steer loader (2017u20132019) worth?

The residual value of the Bobcat S450 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
