S450 Bobcat S450 Specifications & Technical Data (2014—2017)

Model rating
9,00 / 10

The Bobcat S450 is a skid steer loader manufactured by Bobcat from 2014 to 2017. It has a weight of 2.64 tons and a transport leng…

The Bobcat S450 is a skid steer loader manufactured by Bobcat from 2014 to 2017. It has a weight of 2.64 tons and a transport length of 2.5 meters. The bucket capacity is 0.93 cubic meters with a width of 1.727 meters. The maximum discharge height is 2.16 meters. The transport width is 1.49 meters and the transport height is 1.98 meters. The rated operating capacity is 590 kilograms.

Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450
Skid Steer Loaders Bobcat S450

Visit Bobcat live at

Technical specs - S450 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.64 t
Rated operating capacity
590 kg
Standard tyres
10.00-16.5 10 PR
Bucket width
1.727 m
Bucket capacity
0.93 m³
Driver protection
KbR
Transport length
2.5 m
Transport width
1.49 m
Transport height
1.98 m
Travel speed
11.4 km/h
Max. discharge height
2.16 m
Model series
S
Engine manuf.
Kubota
Engine type
V2203M-DI-E
Engine power
36.4 kW
Displacement
2.2 l
Revolutions at max torque
1700 rpm
Emission level
II B

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available...

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, transmission type, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, hydraulic power, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat S450 FAQ

When was the Bobcat S450 manufactured?

The Bobcat S450 was manufactured from 2014 to 2017.

How much does the Bobcat S450 skid steer loader weigh?

The Bobcat S450 skid steer loader weighs 2.64 tons.

What are the transport dimensions of the Bobcat S450 skid steer loader?

The Bobcat S450 has a transport length of 2.5 meters, a transport width of 1.49 meters, and a transport height of 1.98 meters.

What is the travel speed of the Bobcat S450 skid steer loader?

The Bobcat S450 has a travel speed of 11.4 km/h.

What are the undercarriage specifications of the Bobcat S450 skid steer loader?

The Bobcat S450 skid steer loader is equipped with standard tyres sized 10.00-16.5 10 PR.

What is the material handling capacity of the Bobcat S450 skid steer loader?

The Bobcat S450 has a rated operating capacity of 590 kg and a maximum discharge height of 2.16 meters.

What are the specifications of the primary work tool on the Bobcat S450 skid steer loader?

The primary work tool of the Bobcat S450 skid steer loader has a bucket capacity of 0.93 cubic meters and a bucket width of 1.73 meters.

What operator safety and support features does the Bobcat S450 have?

The Bobcat S450 features a cabin with ROPS for driver protection.

How much is a Bobcat S450 Skid steer loader (2014u20132017) worth?

The residual value of the Bobcat S450 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
