MT55 Bobcat MT55 Specifications & Technical Data (2011—2024)

Model rating
3,00 / 10

The Bobcat MT55 is a compact skid steer loader manufactured by Bobcat since 2011. It has a weight of 1.109 tons and a transport le…

The Bobcat MT55 is a compact skid steer loader manufactured by Bobcat since 2011. It has a weight of 1.109 tons and a transport length of 1.838 meters. The loader has a bucket capacity of 1.39 cubic meters and a bucket width of 0.91 meters. It can discharge materials up to a maximum height of 1.26 meters. The transport width and height of the machine are 0.9 meters and 1.25 meters respectively. The track width is 180 millimeters. The Bobcat MT55 has a rated operating capacity of 254 kilograms.

Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55
Skid Steer Loaders Bobcat MT55

Visit Bobcat live at

Technical specs - MT55 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.109 t
Rated operating capacity
254 kg
Track width
180 mm
Bucket width
0.91 m
Bucket capacity
1.39 m³
Steering mode
SL
Transport length
1.838 m
Transport width
0.9 m
Transport height
1.25 m
Travel speed
5.6 km/h
Max. discharge height
1.26 m
Model series
MT
Engine manuf.
Kubota
Engine type
D902E3B
Engine power
18.5 kW
Displacement
0.9 l
Revolutions at max torque
3600 rpm
Max. torque
54.2/2600 Nm
No. of cylinders
3

More technical details, like: standard tyres, driver protection, lifting force, dimension lxwxh, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, engine manufacturer, engine model, number of cylinders...

More technical details, like: standard tyres, driver protection, lifting force, dimension lxwxh, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, engine manufacturer, engine model, number of cylinders, aspiration, rated speed, engine output - net, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, pump flow, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat MT55 FAQ

When was the Bobcat MT55 manufactured?

The Bobcat MT55 was manufactured from 2011 to 2024.

How much does the Bobcat MT55 weigh?

The Bobcat MT55 weighs 1.11 tons.

What are the transport dimensions of the Bobcat MT55 skid steer loader?

The Bobcat MT55 has a transport length of 1.84 meters, a transport width of 0.9 meters, and a transport height of 1.25 meters.

What is the travel speed of the Bobcat MT55 skid steer loader?

The Bobcat MT55 has a travel speed of 5.6 km/h.

What is the track width of the Bobcat MT55 skid steer loader?

The Bobcat MT55 skid steer loader has a track width of 180 mm.

What is the steering mode of the Bobcat MT55?

The Bobcat MT55 has a steering mode of stereo steering.

What is the material handling capacity of the Bobcat MT55 skid steer loader?

The Bobcat MT55 has a rated operating capacity of 254 kg and a maximum discharge height of 1.26 meters.

What are the bucket specifications of the Bobcat MT55 skid steer loader?

The Bobcat MT55 skid steer loader has a bucket capacity of 1.39 cubic meters and a bucket width of 0.91 meters.

How much is a Bobcat MT55 Skid steer loader (2011u20132024) worth?

The residual value of the Bobcat MT55 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Bobcat MT55 overview

Bobcat MT55 features overview

Light and easily transportable

Thanks to its narrow width of 91 cm and compact size, the MT55 allows you to work efficiently in tight spots, indoors and outdoors, all year round. It passes easily through a 1 metre wide door, and you can even drive up and down steps. With an operating weight of only 1186 kg, the MT55 is also very easy to transport on a trailer.


Engine

Performance in a smaller package

With an engine power of 17.5 kW and a load capacity of 254 kg the MT55 is the ideal machine for numerous applications, especially in landscaping and demolition. It eliminates much of the back-breaking and labour intensive work. Moreover, as a tracked machine with low ground pressure, it minimizes damage to lawns and gardens.


Drive system

Ride on it or walk behind it!

Available as a kit, the ride-on platform mounts or dismounts easily in seconds. Pivoting mount with trailer wheel offers a smooth ride. Large standing surface for comfort and convenience.


Frame / loader / backhoes

Versatility taken to the limit!

You can use more than 15 different attachments. The MT55 digs, tills, trenches, sweeps, breaks up concrete, moves material... and much more! You will be amazed at how productive the MT55 can be on any jobsite.
