643 Bobcat 643 Specifications & Technical Data (1987—1992)

The Bobcat 643 is a skid steer loader manufactured by Bobcat from 1987 to 1992. It has a weight of 1.65 tons and a transport lengt…

The Bobcat 643 is a skid steer loader manufactured by Bobcat from 1987 to 1992. It has a weight of 1.65 tons and a transport length of 3.05 meters. The bucket capacity is 0.38 cubic meters, and it has a travel speed of 13 km/h. The transport width is 1.4 meters, and the transport height is 1.92 meters. The rated operating capacity is 453 kilograms.

Skid Steer Loaders Bobcat 643

Visit Bobcat live at

Technical specs - 643 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.65 t
Rated operating capacity
453 kg
Standard tyres
10.0-16.5
Bucket capacity
0.38 m³
Transport length
3.05 m
Transport width
1.4 m
Transport height
1.92 m
Travel speed
13 km/h
Engine manuf.
Kubota
Engine type
D1402
Engine power
22.4 kW

More technical details, like: track width, bucket width, driver protection, steering mode, max. discharge height, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: track width, bucket width, driver protection, steering mode, max. discharge height, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Click and see the specifications of Bobcat 643 in the PDF

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Bobcat 643 FAQ

When was the Bobcat 643 manufactured?

The Bobcat 643 was manufactured from 1987 to 1992.

How much does the Bobcat 643 skid steer loader weigh?

The Bobcat 643 skid steer loader weighs 1.65 tons.

What are the transport dimensions of the Bobcat 643 skid steer loader?

The Bobcat 643 has a transport length of 3.05 meters, a transport width of 1.4 meters, and a transport height of 1.92 meters.

What is the travel speed of the Bobcat 643 skid steer loader?

The Bobcat 643 has a travel speed of 13 km/h.

What are the undercarriage specifications of the Bobcat 643 skid steer loader?

The Bobcat 643 skid steer loader is equipped with standard tyres sized 10.0-16.5.

What is the material handling capacity of the Bobcat 643 skid steer loader?

The Bobcat 643 skid steer loader has a rated operating capacity of 453 kg.

What is the bucket capacity of the Bobcat 643 skid steer loader?

The Bobcat 643 skid steer loader has a bucket capacity of 0.38 cubic meters.

How much is a Bobcat 643 Skid steer loader (1987u20131992) worth?

The residual value of the Bobcat 643 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
