VIO 33 UPR Yanmar excavator specs & dimensions (2015 - 2017)

Yanmar VIO 33 UPR is a mini excavator manufactured from 2015 to 2017. It has a weight of 3.5 tons and a track width of 300 mm. The…

Yanmar VIO 33 UPR is a mini excavator manufactured from 2015 to 2017. It has a weight of 3.5 tons and a track width of 300 mm. The transport dimensions are 4.45 meters in length, 1.55 meters in width, and 2.5 meters in height. The dredging depth is 3.075 meters, and the maximum horizontal reach is 3.38 meters.

Mini Excavators Yanmar VIO 33 UPR

Technical specs - VIO 33 UPR Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.5 t
Transport length
4.45 m
Transport width
1.55 m
Transport height
2.5 m
Track width
300 mm
Driver protection
FD
Max. Reach horizontal
3.38 m
Dredging depth
3.075 m
Model series
VIO
Engine manuf.
Yanmar
Engine type
3TNV82A
Engine power
18.3 kW
Displacement
1.33 l

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, tear-out force, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Yanmar VIO 33 UPR FAQ

When was the Yanmar VIO 33 UPR manufactured?

The Yanmar VIO 33 UPR was manufactured from 2015 to 2017.

How much does the Yanmar VIO 33 UPR weigh?

The Yanmar VIO 33 UPR weighs 3.5 tons.

What are the transport dimensions of the Yanmar VIO 33 UPR mini excavator?

The Yanmar VIO 33 UPR has a transport length of 4.45 meters, a transport width of 1.55 meters, and a transport height of 2.5 meters.

What is the track width of the Yanmar VIO 33 UPR mini excavator?

The Yanmar VIO 33 UPR has a track width of 300 mm.

What are the dredging depth and maximum horizontal reach of the Yanmar VIO 33 UPR mini excavator?

The Yanmar VIO 33 UPR has a dredging depth of 3.075 meters and a maximum horizontal reach of 3.38 meters.

What operator safety and support features does the Yanmar VIO 33 UPR have?

The Yanmar VIO 33 UPR is equipped with a canopy for driver protection.

How much is a Yanmar VIO 33 UPR Mini excavator (2015u20132017) worth?

The residual value of the Yanmar VIO 33 UPR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
