15 John Deere Construction excavator specs & dimensions (1989 - 2021)

John Deere Construction 15 is a mini excavator manufactured from 1989 to 2021. It has a weight of 1.3 tons and a track width of 23…

John Deere Construction 15 is a mini excavator manufactured from 1989 to 2021. It has a weight of 1.3 tons and a track width of 230 mm. The transport dimensions are 3.5 meters in length, 1 meter in width, and 2.1 meters in height. The dredging depth is 2.85 meters, with a maximum horizontal reach of 2 meters. The bucket capacity is 0.4 cubic meters, and it is equipped with a blade.

Mini Excavators John Deere Construction 15

Technical specs - 15 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.3 t
Transport length
3.5 m
Transport width
1 m
Transport height
2.1 m
Bucket capacity
0.4 m³
Track width
230 mm
Max. Reach horizontal
2 m
Dredging depth
2.85 m
Engine manuf.
Yanmar
Engine type
3TNA72-UJB
Engine power
10.8 kW
Displacement
0.87 l
No. of cylinders
3
Cylinder bore x stroke
72x72 mm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, tear-out force, model series, dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 15 FAQ

When was the John Deere Construction 15 manufactured?

The John Deere Construction 15 was manufactured from 1989 to 2021.

How much does the John Deere Construction 15 mini excavator weigh?

The John Deere Construction 15 mini excavator weighs 1.3 tons.

What are the transport dimensions of the John Deere Construction 15 mini excavator?

The John Deere Construction 15 mini excavator has a transport length of 3.5 meters, a transport width of 1 meter, and a transport height of 2.1 meters.

What is the track width of the John Deere Construction 15 mini excavator?

The John Deere Construction 15 mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the John Deere Construction 15 mini excavator?

The John Deere Construction 15 mini excavator has a dredging depth of 2.85 meters and a maximum horizontal reach of 2 meters.

What is the bucket capacity of the John Deere Construction 15 mini excavator?

The John Deere Construction 15 mini excavator has a bucket capacity of 0.4 cubic meters.
