SG12-B5 Shantui SG12-B5 Specifications & Technical Data (2023—2026)

Weight: 7.5t – Standard tyres: 16/70-24 PR16 – Transport length: 7.65m – Transport width: 2.05m – Transport height: 2.96m – Mouldboard width: 3.35m

Graders Shantui SG12-B5

Technical specs - SG12-B5 Shantui

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.5 t
Standard tyres
16/70-24 PR16
Transport length
7.65 m
Transport width
2.05 m
Transport height
2.96 m
Mouldboard width
3.35 m
Travel speed
40 km/h
Engine manuf.
Cummins
Engine type
4BA3.9-C125-II
Engine power
93 kW
Displacement
3.9 l
Revolutions at max torque
1500 rpm
Max. torque
475 Nm
No. of cylinders
4
Emission level
China II

More technical details, like: steering mode, drive, front blade width, turning radius outside, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
No
Front blade
No
Rear ripper
No
Aircondition
No

Download datasheets (PDF)

Shantui SG12-B5 FAQ

When was the Shantui SG12-B5 manufactured?

The Shantui SG12-B5 was first produced in 2023.

How much does the Shantui SG12-B5 grader weigh?

The Shantui SG12-B5 grader weighs 7.5 tons.

What are the transport dimensions of the Shantui SG12-B5 grader?

The Shantui SG12-B5 grader has a transport length of 7.65 meters, a transport width of 2.05 meters, and a transport height of 2.96 meters.

What is the travel speed of the Shantui SG12-B5 grader?

The Shantui SG12-B5 grader has a travel speed of 40 km/h.

What is the front blade width of the Shantui SG12-B5 grader?

The front blade width of the Shantui SG12-B5 grader is 3.35 meters.

How much is a Shantui SG12-B5 Grader (2023u20132025) worth?

The residual value of the Shantui SG12-B5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
