ECR355ENL Volvo excavator specs & Dimensions (2019 - 2023)

Volvo ECR355ENL is a crawler excavator manufactured since 2019. It has a weight of 36.42 tons and a track width of 600 mm. The tra…

Volvo ECR355ENL is a crawler excavator manufactured since 2019. It has a weight of 36.42 tons and a track width of 600 mm. The transport dimensions are 9.95 meters in length, 2.99 meters in width, and 3.61 meters in height. The machine features a tear-out force of 192 kN, a dredging depth of 6.46 meters, and a maximum horizontal reach of 10.11 meters. The bucket capacity is 1.27 cubic meters.

Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL
Crawler Excavators Volvo ECR355ENL

Visit Volvo live at

Technical specs - ECR355ENL Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
36.42 t
Transport length
9.95 m
Transport width
2.99 m
Transport height
3.61 m
Bucket capacity
1.27 m³
Track width
600 mm
Max. Reach horizontal
10.11 m
Dredging depth
6.46 m
Tear-out force
192 kN
Model series
ECR
Engine manuf.
Volvo
Engine type
D8J
Engine power
179 kW
Displacement
7.8 l
Revolutions at max torque
1800 rpm
Max. torque
1238/1350 Nm
No. of cylinders
6
Cylinder bore x stroke
110x136 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo ECR355ENL FAQ

When was the Volvo ECR355ENL manufactured?

The Volvo ECR355ENL was manufactured from 2019 to 2023.

How much does the Volvo ECR355ENL weigh?

The Volvo ECR355ENL weighs 36.42 tons.

What are the transport dimensions of the Volvo ECR355ENL crawler excavator?

The Volvo ECR355ENL has a transport length of 9.95 meters, a transport width of 2.99 meters, and a transport height of 3.61 meters.

What is the fuel consumption range of the Volvo ECR355ENL crawler excavator?

The Volvo ECR355ENL crawler excavator has a fuel consumption range of 14 to 28 liters per hour.

What is the track width of the Volvo ECR355ENL's undercarriage?

The Volvo ECR355ENL has a track width of 600 mm.

What are the excavation performance specifications of the Volvo ECR355ENL?

The Volvo ECR355ENL has a dredging depth of 6.46 meters and a maximum horizontal reach of 10.11 meters.

What power rating information is available for the Volvo ECR355ENL?

The source data does not provide power rating information for the Volvo ECR355ENL. It only specifies a tear-out force of 192 kN, which is a force measurement, not a power rating.

What is the bucket capacity of the Volvo ECR355ENL crawler excavator?

The bucket capacity of the Volvo ECR355ENL crawler excavator is 1.27 cubic meters.

How much is a Volvo ECR355ENL Crawler excavator (2019u20132023) worth?

The residual value of the Volvo ECR355ENL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
