Technical specs - EC750E Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 73.5 t
- Transport length
- 12.2 m
- Transport width
- 4.29 m
- Transport height
- 4.855 m
- Track width
- 650 mm
- Max. Reach horizontal
- 11.46 m
- Dredging depth
- 7.21 m
- Tear-out force
- 362 kN
- Bucket width
- 2.9 m
- Model series
- EC
- Engine manuf.
- Volvo
- Engine type
- D16J
- Engine power
- 392 kW
- Displacement
- 16.1 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 2570/1350 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 144x165 mm
- Emission level
- V
More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh are available in the full technical specs.
Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket
Special equipment
- Diesel particulate filter
-
No
- Track adjustment
-
No
- Blade
-
No
- Cabin adjustment
-
No
- Overload alert
-
No
- Material Handling Excavator
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
