EC330B LC Volvo excavator specs & Dimensions (2001 - 2009)

Volvo EC330B LC is a crawler excavator manufactured from 2001 to 2009. It has a weight of 33.8 tons and a track width of 600 mm. T…

Volvo EC330B LC is a crawler excavator manufactured from 2001 to 2009. It has a weight of 33.8 tons and a track width of 600 mm. The transport dimensions are 11.16 meters in length, 3.39 meters in width, and 3.7 meters in height. The excavator features a tear-out force of 207 kN, a dredging depth of 8.08 meters, and a maximum horizontal reach of 11.5 meters. It is equipped with a bucket capacity of 2.5 cubic meters.

Crawler Excavators Volvo EC330B LC

Visit Volvo live at

Technical specs - EC330B LC Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
33.8 t
Transport length
11.16 m
Transport width
3.39 m
Transport height
3.7 m
Bucket capacity
2.5 m³
Track width
600 mm
Max. Reach horizontal
11.5 m
Dredging depth
8.08 m
Tear-out force
207 kN
Engine manuf.
Volvo
Engine type
D10B EAE2
Engine power
198 kW
Displacement
9.6 l
Revolutions at max torque
1700 rpm
Max. torque
1255/1400 Nm
No. of cylinders
6
Cylinder bore x stroke
121x140 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC330B LC FAQ

When was the Volvo EC330B LC manufactured?

The Volvo EC330B LC was manufactured from 2001 to 2009.

How much does the Volvo EC330B LC weigh?

The Volvo EC330B LC weighs 33.8 tons.

What are the transport dimensions of the Volvo EC330B LC crawler excavator?

The Volvo EC330B LC has a transport length of 11.16 meters, a transport width of 3.39 meters, and a transport height of 3.7 meters.

What is the track width of the Volvo EC330B LC's undercarriage?

The Volvo EC330B LC has a track width of 600 mm in its undercarriage.

What are the excavation performance specifications of the Volvo EC330B LC?

The Volvo EC330B LC has a dredging depth of 8.08 meters and a maximum horizontal reach of 11.5 meters.

What is the tear-out force rating of the Volvo EC330B LC?

The Volvo EC330B LC has a tear-out force rating of 207 kN.

What is the bucket capacity of the Volvo EC330B LC excavator?

The Volvo EC330B LC excavator has a bucket capacity of 2.5 cubic meters.

How much is a Volvo EC330B LC Crawler excavator (2001u20132009) worth?

The residual value of the Volvo EC330B LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Volvo EC330B LC overview

Engine

Engine

The engine is a turbocharged, 4-stroke diesel engine with water cooling, direct injection and charged air cooler that meets EPA Tier 2 emission standards. The engine has been developed especially for excavator use, providing good fuel economy, low noise levels and a long service life.


Hydraulic and electronic system

Swing system

The superstructure is swung by the means of an axial piston motor and a planetary reduction gear. Automatic swing holding brake and anti-rebound valve are standard.


Drive

Each track is powered by an automatic two-speed travel motor. The track brakes are multi-disc, spring-applied and hydraulic released. The travel motor, brake and planetary gears are well protected in the track frame.
