EC140ELM Volvo excavator specs & Dimensions (2019 - 2023)

Volvo EC140ELM is a Crawler Excavator manufactured since 2019. It has a weight of 15.78 tons and a track width of 600 mm. The tran…

Volvo EC140ELM is a Crawler Excavator manufactured since 2019. It has a weight of 15.78 tons and a track width of 600 mm. The transport dimensions are 7.69 meters in length, 2.69 meters in width, and 2.994 meters in height. The machine offers a tear-out force of 80.5 kN, a dredging depth of 4.96 meters, and a maximum horizontal reach of 7.98 meters.

Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM
Crawler Excavators Volvo EC140ELM

Visit Volvo live at

Technical specs - EC140ELM Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.78 t
Transport length
7.69 m
Transport width
2.69 m
Transport height
2.994 m
Track width
600 mm
Boom
MB
Max. Reach horizontal
7.98 m
Dredging depth
4.96 m
Tear-out force
80.5 kN
Model series
EC
Engine manuf.
Volvo
Engine type
D4J
Engine power
89 kW
Displacement
4 l
Revolutions at max torque
2000 rpm
Max. torque
566/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
101x126 mm
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC140ELM FAQ

When was the Volvo EC140ELM manufactured?

The Volvo EC140ELM was manufactured from 2019 to 2023.

How much does the Volvo EC140ELM weigh?

The Volvo EC140ELM weighs 15.78 tons.

What are the transport dimensions of the Volvo EC140ELM crawler excavator?

The Volvo EC140ELM has a transport length of 7.69 meters, a transport width of 2.69 meters, and a transport height of 2.99 meters.

What is the track width of the Volvo EC140ELM's undercarriage?

The Volvo EC140ELM has a track width of 600 mm.

What are the excavation performance specifications of the Volvo EC140ELM?

The Volvo EC140ELM has a dredging depth of 4.96 meters, a maximum horizontal reach of 7.98 meters, and features a monobloc boom.

What is the tear-out force of the Volvo EC140ELM?

The Volvo EC140ELM has a tear-out force of 80.5 kN.

How much is a Volvo EC140ELM Crawler excavator (2019u20132023) worth?

The residual value of the Volvo EC140ELM depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
