PC75-1 Komatsu excavator specs & Dimensions (1998 - 1999)

Model rating
1,00 / 10

Komatsu PC75-1 is a Crawler Excavator manufactured from 1998 to 1999, with a weight of 7.4 tons. It has a transport length of 5.9 …

Komatsu PC75-1 is a Crawler Excavator manufactured from 1998 to 1999, with a weight of 7.4 tons. It has a transport length of 5.9 meters, a transport width of 2.7 meters, and a transport height of 2.1 meters.

Crawler Excavators Komatsu PC75-1

Visit Komatsu live at

Technical specs - PC75-1 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.4 t
Transport length
5.9 m
Transport width
2.7 m
Transport height
2.1 m
Bucket capacity
0.27 m³
Model series
PC
Engine manuf.
Komatsu
Engine type
4D98E
Engine power
32 kW

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, boom, max. reach horizontal, dredging depth, tear-out force, bucket width, dimension lxwxh, displacement, revolutions at max torque...

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, boom, max. reach horizontal, dredging depth, tear-out force, bucket width, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC75-1 FAQ

When was the Komatsu PC75-1 manufactured?

The Komatsu PC75-1 was manufactured from 1998 to 1999.

How much does the Komatsu PC75-1 weigh?

The Komatsu PC75-1 weighs 7.4 tons.

What are the transport dimensions of the Komatsu PC75-1?

The Komatsu PC75-1 has a transport length of 5.9 meters, a transport width of 2.7 meters, and a transport height of 2.1 meters.

What is the bucket capacity of the Komatsu PC75-1?

The bucket capacity of the Komatsu PC75-1 is 0.27 cubic meters.

How much is a Komatsu PC75-1 Crawler excavator (1998u20131999) worth?

The residual value of the Komatsu PC75-1 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
