PC200-3 Komatsu excavator specs & Dimensions (1986 - 1989)

Komatsu PC200-3 is a Crawler Excavator manufactured from 1986 to 1989. It has a weight of 18.416 tons and a track width of 710 mm.…

Komatsu PC200-3 is a Crawler Excavator manufactured from 1986 to 1989. It has a weight of 18.416 tons and a track width of 710 mm. The transport dimensions are 9.38 meters in length, 3.09 meters in width, and 2.875 meters in height. The dredging depth is 7.68 meters, and the maximum horizontal reach is 10.69 meters. The bucket width is 1.45 meters, with a capacity of 1.17 cubic meters.

Crawler Excavators Komatsu PC200-3

Visit Komatsu live at

Technical specs - PC200-3 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.416 t
Transport length
9.38 m
Transport width
3.09 m
Transport height
2.875 m
Bucket capacity
1.17 m³
Undercarriage
SL
Track width
710 mm
Boom
MB
Max. Reach horizontal
10.69 m
Dredging depth
7.68 m
Bucket width
1.45 m
Model series
PC
Engine manuf.
Komatsu
Engine type
S6D105
Engine power
88 kW
Displacement
6.49 l
Revolutions at max torque
2100 rpm
No. of cylinders
6
Cylinder bore x stroke
105x125 mm

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC200-3 FAQ

When was the Komatsu PC200-3 manufactured?

The Komatsu PC200-3 was manufactured from 1986 to 1989.

How much does the Komatsu PC200-3 weigh?

The Komatsu PC200-3 weighs 18.42 tons.

What are the transport dimensions of the Komatsu PC200-3?

The Komatsu PC200-3 has a transport length of 9.38 meters, a transport width of 3.09 meters, and a transport height of 2.88 meters.

What are the undercarriage specifications of the Komatsu PC200-3?

The Komatsu PC200-3 has a standard undercarriage with a track width of 710 mm.

What are the excavation performance specifications of the Komatsu PC200-3?

The Komatsu PC200-3 has a dredging depth of 7.68 meters, a maximum horizontal reach of 10.69 meters, and is equipped with a monobloc boom.

What are the specifications of the primary work tool bucket on the Komatsu PC200-3?

The primary work tool bucket of the Komatsu PC200-3 has a capacity of 1.17 cubic meters and a width of 1.45 meters.

How much is a Komatsu PC200-3 Crawler excavator (1986u20131989) worth?

The residual value of the Komatsu PC200-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
