PC150-3 Komatsu excavator specs & Dimensions (1988 - 1995)

Komatsu PC150-3 is a crawler excavator manufactured from 1988 to 1995, with a weight of 14.7 tons. It features a track width of 51…

Komatsu PC150-3 is a crawler excavator manufactured from 1988 to 1995, with a weight of 14.7 tons. It features a track width of 510 mm, a transport length of 8.45 meters, a transport width of 2.5 meters, and a transport height of 2.82 meters. The bucket capacity is 0.75 cubic meters.

Crawler Excavators Komatsu PC150-3

Visit Komatsu live at

Technical specs - PC150-3 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.7 t
Transport length
8.45 m
Transport width
2.5 m
Transport height
2.82 m
Bucket capacity
0.75 m³
Undercarriage
SL
Track width
510 mm
Boom
MB
Model series
PC
Engine manuf.
Komatsu
Engine type
S6D95L
Engine power
74 kW
Displacement
4.89 l
Revolutions at max torque
2200 rpm

More technical details, like: bucket capacity min., bucket capacity max., max. reach horizontal, dredging depth, tear-out force, bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC150-3 FAQ

When was the Komatsu PC150-3 manufactured?

The Komatsu PC150-3 was manufactured from 1988 to 1995.

How much does the Komatsu PC150-3 weigh?

The Komatsu PC150-3 weighs 14.7 tons.

What are the transport dimensions of the Komatsu PC150-3?

The Komatsu PC150-3 has a transport length of 8.45 meters, a transport width of 2.5 meters, and a transport height of 2.82 meters.

What are the undercarriage specifications of the Komatsu PC150-3?

The Komatsu PC150-3 has a standard undercarriage with a track width of 510 mm.

What type of boom does the Komatsu PC150-3 have?

The Komatsu PC150-3 has a monobloc boom.

What is the bucket capacity of the Komatsu PC150-3?

The Komatsu PC150-3 has a bucket capacity of 0.75 cubic meters.

How much is a Komatsu PC150-3 Crawler excavator (1988u20131995) worth?

The residual value of the Komatsu PC150-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
