SK 85 CS 7 Kobelco excavator specs & Dimensions (2022 - 2026)

Kobelco SK 85 CS 7 is a Crawler Excavator manufactured since 2022. It has a weight of 9.12 tons and a track width of 600 mm. The t…

Kobelco SK 85 CS 7 is a Crawler Excavator manufactured since 2022. It has a weight of 9.12 tons and a track width of 600 mm. The transport dimensions are 6.75 meters in length, 2.45 meters in width, and 2.57 meters in height. The excavator features a tear-out force of 77 kN, a dredging depth of 4.44 meters, and a maximum horizontal reach of 6.26 meters. The bucket capacity ranges from 0.11 m³ to 0.28 m³. Special equipment includes air conditioning, a blade, a diesel particulate filter, an overload alert, and track adjustment.

Crawler Excavators Kobelco SK 85 CS 7

Visit Kobelco live at

Technical specs - SK 85 CS 7 Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.12 t
Transport length
6.75 m
Transport width
2.45 m
Transport height
2.57 m
Bucket capacity min.
0.11 m³
Bucket capacity max.
0.28 m³
Track width
600 mm
Max. Reach horizontal
6.26 m
Dredging depth
4.44 m
Tear-out force
77 kN
Model series
SK
Engine manuf.
Yanmar
Engine type
4TNV98CT
Engine power
52.3 kW
Displacement
3.318 l
Revolutions at max torque
2100 rpm
Max. torque
293 Nm
No. of cylinders
4
Cylinder bore x stroke
98x110 mm
Emission level
Tier 4 Final

More technical details, like: bucket capacity, undercarriage, boom, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 85 CS 7 FAQ

When was the Kobelco SK 85 CS 7 manufactured?

The Kobelco SK 85 CS 7 was first produced in 2022.

How much does the Kobelco SK 85 CS 7 weigh?

The Kobelco SK 85 CS 7 weighs 9.12 tons.

What are the transport dimensions of the Kobelco SK 85 CS 7?

The Kobelco SK 85 CS 7 has a transport length of 6.75 meters, a transport width of 2.45 meters, and a transport height of 2.57 meters.

What is the track width of the Kobelco SK 85 CS 7's undercarriage?

The Kobelco SK 85 CS 7 has a track width of 600 mm.

What is the excavation performance of the Kobelco SK 85 CS 7?

The Kobelco SK 85 CS 7 has a dredging depth of 4.44 meters and a maximum horizontal reach of 6.26 meters.

What is the tear-out force of the Kobelco SK 85 CS 7?

The Kobelco SK 85 CS 7 has a tear-out force of 77 kN. No power rating data is available for this machine.

What are the bucket capacity specifications of the Kobelco SK 85 CS 7 excavator?

The Kobelco SK 85 CS 7 excavator has a bucket capacity ranging from 0.11 to 0.28 cubic meters.

How much is a Kobelco SK 85 CS 7 Crawler excavator (2022u20132025) worth?

The residual value of the Kobelco SK 85 CS 7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
