Technical specs - JS300NLC XD JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 31.01 t
- Transport length
- 10.76 m
- Transport width
- 2.99 m
- Transport height
- 3.37 m
- Bucket capacity
- 1.9 m³
- Undercarriage
- NLC
- Track width
- 600 mm
- Boom
- MB
- Max. Reach horizontal
- 9.87 m
- Dredging depth
- 6.48 m
- Tear-out force
- 247.3 kN
- Bucket width
- 1.7 m
- Model series
- JS
- Engine manuf.
- MTU
- Engine type
- 6 R 1000
- Engine power
- 180 kW
- Displacement
- 7.7 l
- No. of cylinders
- 6
- Emission level
- IV
More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket
Special equipment
- Diesel particulate filter
-
No
- Track adjustment
-
No
- Blade
-
No
- Cabin adjustment
-
No
- Overload alert
-
No
- Material Handling Excavator
-
No
- Aircondition
-
Yes
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
