JS300NLC JCB excavator specs & Dimensions (2017 - 2021)

JCB JS300NLC is a crawler excavator manufactured from 2017 to 2021, with a weight of 31.01 tons. It features a track width of 600 …

JCB JS300NLC is a crawler excavator manufactured from 2017 to 2021, with a weight of 31.01 tons. It features a track width of 600 mm, a transport length of 10.76 meters, a transport width of 2.99 meters, and a transport height of 3.37 meters. The machine has a tear-out force of 247.3 kN, a dredging depth of 6.48 meters, and a maximum horizontal reach of 9.87 meters. The bucket width is 1.7 meters, with a bucket capacity of 1.9 cubic meters. It is equipped with air conditioning.

Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC
Crawler Excavators JCB JS300NLC

Visit JCB live at

Technical specs - JS300NLC JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
31.01 t
Transport length
10.76 m
Transport width
2.99 m
Transport height
3.37 m
Bucket capacity
1.9 m³
Undercarriage
NLC
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.87 m
Dredging depth
6.48 m
Tear-out force
247.3 kN
Bucket width
1.7 m
Model series
JS
Engine manuf.
MTU
Engine type
6 R 1000
Engine power
180 kW
Displacement
7.7 l
No. of cylinders
6
Emission level
IV

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB JS300NLC FAQ

When was the JCB JS300NLC manufactured?

The JCB JS300NLC was manufactured from 2017 to 2021.

How much does the JCB JS300NLC weigh?

The JCB JS300NLC weighs 31.01 tons.

What are the transport dimensions of the JCB JS300NLC crawler excavator?

The JCB JS300NLC has a transport length of 10.76 meters, a transport width of 2.99 meters, and a transport height of 3.37 meters.

What are the undercarriage specifications of the JCB JS300NLC?

The JCB JS300NLC has a small undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the JCB JS300NLC?

The JCB JS300NLC has a dredging depth of 6.48 meters, a maximum horizontal reach of 9.87 meters, and is equipped with a monobloc boom.

What are the power ratings of the JCB JS300NLC?

There is no power rating information available for the JCB JS300NLC in the provided data.

What are the bucket specifications of the JCB JS300NLC excavator?

The JCB JS300NLC excavator has a bucket capacity of 1.9 cubic meters and a bucket width of 1.7 meters.

How much is a JCB JS300NLC Crawler excavator (2017u20132021) worth?

The residual value of the JCB JS300NLC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
