JS145LC JCB excavator specs & Dimensions (2012 - 2020)

JCB JS145LC is a Crawler Excavator manufactured from 2012 to 2020, with a weight of 15.28 tons. It features a track width of 600 m…

JCB JS145LC is a Crawler Excavator manufactured from 2012 to 2020, with a weight of 15.28 tons. It features a track width of 600 mm, a transport length of 7.51 meters, a transport width of 2.8 meters, and a transport height of 3.15 meters. The machine has a tear-out force of 72.5 kN, a dredging depth of 4.66 meters, and a maximum horizontal reach of 7.52 meters. The bucket width is 0.7 meters, with a bucket capacity of 0.42 cubic meters. Special equipment includes air conditioning and a blade.

Crawler Excavators JCB JS145LC

Visit JCB live at

Technical specs - JS145LC JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.28 t
Transport length
7.51 m
Transport width
2.8 m
Transport height
3.15 m
Bucket capacity
0.42 m³
Undercarriage
LC
Track width
600 mm
Boom
VA
Max. Reach horizontal
7.52 m
Dredging depth
4.66 m
Tear-out force
72.5 kN
Bucket width
0.7 m
Model series
JS
Engine manuf.
JCB
Engine type
444 TCA
Engine power
81 kW
Displacement
4.4 l
Revolutions at max torque
2050 rpm
Emission level
Tier 4i/3b

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB JS145LC FAQ

When was the JCB JS145LC manufactured?

The JCB JS145LC was manufactured from 2012 to 2020.

How much does the JCB JS145LC weigh?

The JCB JS145LC weighs 15.28 tons.

What are the transport dimensions of the JCB JS145LC crawler excavator?

The JCB JS145LC has a transport length of 7.51 meters, a transport width of 2.8 meters, and a transport height of 3.15 meters.

What are the undercarriage specifications of the JCB JS145LC?

The JCB JS145LC has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the JCB JS145LC crawler excavator?

The JCB JS145LC crawler excavator has a dredging depth of 4.66 meters, a maximum horizontal reach of 7.52 meters, and features an adjustable boom.

What is the tear-out force of the JCB JS145LC?

The JCB JS145LC has a tear-out force of 72.5 kN.

What are the specifications of the primary work tool on the JCB JS145LC?

The primary work tool of the JCB JS145LC has a bucket capacity of 0.42 cubic meters and a bucket width of 0.7 meters.

How much is a JCB JS145LC Crawler excavator (2012u20132020) worth?

The residual value of the JCB JS145LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
