JS130 LC JCB excavator specs & Dimensions (2012 - 2026)

JCB JS130 LC is a Crawler Excavator manufactured since 2012, with a weight of 14.02 tons. It features a track width of 600 mm, a t…

JCB JS130 LC is a Crawler Excavator manufactured since 2012, with a weight of 14.02 tons. It features a track width of 600 mm, a transport length of 7.51 meters, a transport width of 2.59 meters, and a transport height of 3 meters. The machine has a tear-out force of 72.5 kN, a dredging depth of 4.81 meters, and a maximum horizontal reach of 7.52 meters. The bucket width is 0.61 meters with a capacity of 0.34 cubic meters. Special equipment includes air conditioning and a blade.

Crawler Excavators JCB JS130 LC
Crawler Excavators JCB JS130 LC
Crawler Excavators JCB JS130 LC
Crawler Excavators JCB JS130 LC

Visit JCB live at

Technical specs - JS130 LC JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.02 t
Transport length
7.51 m
Transport width
2.59 m
Transport height
3 m
Bucket capacity
0.34 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
7.52 m
Dredging depth
4.81 m
Tear-out force
72.5 kN
Bucket width
0.61 m
Model series
JS
Engine manuf.
JCB
Engine type
444 TCA
Engine power
81 kW
Displacement
4.4 l
Revolutions at max torque
2050 rpm
Emission level
Tier 4i/3b

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB JS130 LC FAQ

When was the JCB JS130 LC manufactured?

The JCB JS130 LC was first produced in 2012.

How much does the JCB JS130 LC weigh?

The JCB JS130 LC weighs 14.02 tons.

What are the transport dimensions of the JCB JS130 LC?

The JCB JS130 LC has a transport length of 7.51 meters, a transport width of 2.59 meters, and a transport height of 3 meters.

What are the undercarriage specifications of the JCB JS130 LC?

The JCB JS130 LC has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the JCB JS130 LC?

The JCB JS130 LC has a dredging depth of 4.81 meters, a maximum horizontal reach of 7.52 meters, and is equipped with a monobloc boom.

What is the tear-out force rating of the JCB JS130 LC crawler excavator?

The JCB JS130 LC crawler excavator has a tear-out force rating of 72.5 kN.

What are the bucket specifications of the JCB JS130 LC excavator?

The JCB JS130 LC excavator has a bucket capacity of 0.34 cubic meters and a bucket width of 0.61 meters.

How much is a JCB JS130 LC Crawler excavator (2012u20132025) worth?

The residual value of the JCB JS130 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
