150X HD JCB excavator specs & Dimensions (2021 - 2026)

JCB 150X HD is a Crawler Excavator manufactured since 2020, with a weight of 17.151 tons and a track width of 600 mm. It has a tra…

JCB 150X HD is a Crawler Excavator manufactured since 2020, with a weight of 17.151 tons and a track width of 600 mm. It has a transport length of 7.89 meters, a transport width of 2.8 meters, and a transport height of 3.36 meters. The dredging depth is 5.9 meters, and the maximum horizontal reach is 8.8 meters. The bucket width is 1.35 meters, with a capacity ranging from 0.21 to 0.89 cubic meters. Special equipment includes air conditioning and a diesel particulate filter.

Crawler Excavators JCB 150X HD

Visit JCB live at

Technical specs - 150X HD JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.151 t
Transport length
7.89 m
Transport width
2.8 m
Transport height
3.36 m
Bucket capacity
0.89 m³
Bucket capacity min.
0.21 m³
Bucket capacity max.
0.89 m³
Undercarriage
HD
Track width
600 mm
Boom
VA
Max. Reach horizontal
8.8 m
Dredging depth
5.9 m
Bucket width
1.35 m
Model series
X
Engine manuf.
JCB
Engine type
DieselMax
Engine power
81 kW
Displacement
4.8 l
Revolutions at max torque
1450 rpm
No. of cylinders
4
Emission level
V

More technical details, like: tear-out force, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

JCB 150X HD FAQ

When was the JCB 150X HD manufactured?

The JCB 150X HD was first produced in 2021.

How much does the JCB 150X HD weigh?

The JCB 150X HD weighs 17.15 tons.

What are the transport dimensions of the JCB 150X HD?

The JCB 150X HD has a transport length of 7.89 meters, a transport width of 2.8 meters, and a transport height of 3.36 meters.

What are the undercarriage specifications of the JCB 150X HD?

The JCB 150X HD has a heavy duty undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the JCB 150X HD?

The JCB 150X HD has a dredging depth of 5.9 meters, a maximum horizontal reach of 8.8 meters, and features an adjustable boom.

What are the bucket specifications of the JCB 150X HD crawler excavator?

The JCB 150X HD has a bucket capacity ranging from 0.21 to 0.89 cubic meters, with a bucket width of 1.35 meters.

How much is a JCB 150X HD Crawler excavator (2021u20132025) worth?

The residual value of the JCB 150X HD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
