932 John Deere 932 Specifications & Technical Data (1979—1982)

The John Deere 932 Combine Harvester, manufactured from 1979 to 1982, weighs 4.24 tons and has an engine power of 41.8 kW. It has …

The John Deere 932 Combine Harvester, manufactured from 1979 to 1982, weighs 4.24 tons and has an engine power of 41.8 kW. It has a transport length of 7.8 meters, a transport width of 2.81 meters, and a transport height of 3.25 meters. The harvester is equipped with 3 walkers and has a grain tank size of 17600 liters. The cutting platform width is 2.65 meters.

Combine Harvesters John Deere 932

Technical specs - 932 John Deere

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
41.8 kW
Standard tyres
F:18.4-26/R:10.5-18
Walkers
3
Grain tank size
17600 l
Transmission type
M
Weight
4.24 t
Transport length
7.8 m
Transport width
2.81 m
Transport height
3.25 m
Engine manuf.
John Deere
Engine type
3179
Displacement
2.94 l
No. of cylinders
3

More technical details, like: model series, threshing system, rotor Ø, steering, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
No
Straw chopper
No
Stone Trap
No
Hillside levelling
No
Chaff spreader
No
Loss monitoring
No
Rollover protection
No
All-wheel drive
No
Aircondition
No

John Deere 932 FAQ

When was the John Deere 932 manufactured?

The John Deere 932 was manufactured from 1979 to 1982.

What is the weight of the John Deere 932 combine harvester?

The John Deere 932 combine harvester weighs 4.24 tonnes.

What are the transport dimensions of the John Deere 932 combine harvester?

The John Deere 932 has a transport length of 7.8 meters, a transport width of 2.81 meters, and a transport height of 3.25 meters.

What is the engine power of the John Deere 932 combine harvester?

The John Deere 932 combine harvester has an engine power of 41.8 kW.

What type of transmission does the John Deere 932 have?

The John Deere 932 is equipped with a mechanical power shift transmission.

What are the standard tyre specifications for the John Deere 932 combine harvester?

The John Deere 932 combine harvester is equipped with standard tyres sized F:18.4-26 for the front and R:10.5-18 for the rear.

What is the grain tank volume capacity of the John Deere 932 combine harvester?

The John Deere 932 combine harvester has a grain tank size of 17,600 liters.

What is the threshing and separation system of the John Deere 932?

The John Deere 932 uses a threshing and separation system with 3 walkers.

How much is a John Deere 932 Combine Harvester (1979u20131982) worth?

The residual value of the John Deere 932 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
