Case IH Axial Flow 5130
- Engine power:
- 200 kW
- Model series:
- Axial-Flow
- Standard tyres:
- 800/65R32
- Threshing system:
- R
.png)
Case IH Axial Flow 5130 Specifications & Technical Data (2011-2014)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - Axial Flow 5130 Case IH
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Engine power
- 200 kW
- Model series
- Axial-Flow
- Standard tyres
- 800/65R32
- Threshing system
- R
- Grain tank size
- 8800 l
- Steering
- HH
- Transmission type
- h
- Weight
- 15.5 t
- Transport length
- 7.92 m
- Transport width
- 3.49 m
- Engine manuf.
- Case IH
- Engine type
- NEF 6.7
More technical details, like: walkers, rotor Ø, transport height, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.
Special equipment
- Cabin
-
Yes
- Straw chopper
-
Yes
- Stone Trap
-
Yes
- Hillside levelling
-
Yes
- Chaff spreader
-
Yes
- Loss monitoring
-
No
- Rollover protection
-
No
- All-wheel drive
-
No
- Aircondition
-
Yes
Download datasheets (PDF)
