930 John Deere 930 Specifications & Technical Data (1972—1974)

The John Deere 930 Combine Harvester, manufactured from 1972 to 1974, weighs 4.63 tons and has an engine power of 48.5 kW. It has …

The John Deere 930 Combine Harvester, manufactured from 1972 to 1974, weighs 4.63 tons and has an engine power of 48.5 kW. It has a transport length of 6.45 meters, a transport width of 2.43 meters, and a transport height of 2.92 meters. The harvester is equipped with 3 walkers and has a grain tank size of 17,500 liters. The cutting platform width is 2.6 meters.

Combine Harvesters John Deere 930

Technical specs - 930 John Deere

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
48.5 kW
Standard tyres
F:16.9-24/R:7.50-16
Walkers
3
Grain tank size
17500 l
Transmission type
M
Weight
4.63 t
Transport length
6.45 m
Transport width
2.43 m
Transport height
2.92 m
Engine manuf.
John Deere
Engine type
4219 DZ05
Displacement
3.59 l
No. of cylinders
4

More technical details, like: model series, threshing system, rotor Ø, steering, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
No
Straw chopper
No
Stone Trap
No
Hillside levelling
No
Chaff spreader
No
Loss monitoring
No
Rollover protection
No
All-wheel drive
No
Aircondition
No

John Deere 930 FAQ

When was the John Deere 930 manufactured?

The John Deere 930 was manufactured from 1972 to 1974.

What is the weight of the John Deere 930 combine harvester?

The John Deere 930 combine harvester has a weight of 4.63 tonnes.

What are the transport dimensions of the John Deere 930 combine harvester?

The John Deere 930 has a transport length of 6.45 meters, a transport width of 2.43 meters, and a transport height of 2.92 meters.

What is the engine power of the John Deere 930 combine harvester?

The John Deere 930 combine harvester has an engine power of 48.5 kW.

What type of transmission does the John Deere 930 have?

The John Deere 930 is equipped with a mechanical power shift transmission.

What are the standard tyre specifications for the John Deere 930 combine harvester?

The John Deere 930 combine harvester is equipped with standard tyres sized F:16.9-24 for the front and R:7.50-16 for the rear.

What is the grain tank volume capacity of the John Deere 930?

The John Deere 930 has a grain tank size of 17,500 liters.

What is the threshing and separation system of the John Deere 930?

The John Deere 930 uses a threshing and separation system with 3 walkers.

How much is a John Deere 930 Combine Harvester (1972u20131974) worth?

The residual value of the John Deere 930 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
