Dominator 96 Claas Dominator 96 Specifications & Technical Data (1978—1985)

Engine power: 112kW – Model series: Dominator – Standard tyres: F:23.1-26/R:14.5-20 – Walkers: 5 – Grain tank size: 5200l – Transmission type: M

Combine Harvesters Claas Dominator 96

Technical specs - Dominator 96 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
112 kW
Model series
Dominator
Standard tyres
F:23.1-26/R:14.5-20
Walkers
5
Grain tank size
5200 l
Transmission type
M
Transport length
10.5 m

More technical details, like: threshing system, rotor Ø, steering, weight, transport width, transport height, engine manuf., engine type, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: threshing system, rotor Ø, steering, weight, transport width, transport height, engine manuf., engine type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Straw chopper
No
Stone Trap
No
Hillside levelling
No
Chaff spreader
No
Loss monitoring
No
Rollover protection
No
All-wheel drive
No
Aircondition
No

Claas Dominator 96 FAQ

When was the Claas Dominator 96 manufactured?

The Claas Dominator 96 was manufactured from 1978 to 1985.

What is the transport length of the Claas Dominator 96 combine harvester?

The Claas Dominator 96 has a transport length of 10.5 meters.

What is the engine power of the Claas Dominator 96?

The Claas Dominator 96 has an engine power of 112 kW.

What type of transmission does the Claas Dominator 96 have?

The Claas Dominator 96 is equipped with a mechanical power shift transmission.

What are the standard tyre specifications for the Claas Dominator 96 combine harvester?

The Claas Dominator 96 is equipped with standard tyres sized F:23.1-26 for the front and R:14.5-20 for the rear.

What is the grain tank volume capacity of the Claas Dominator 96?

The Claas Dominator 96 has a grain tank size of 5200 liters.

What is the threshing and separation system of the Claas Dominator 96?

The Claas Dominator 96 uses a threshing and separation system with 5 walkers.

How much is a Claas Dominator 96 Combine Harvester (1978u20131985) worth?

The residual value of the Claas Dominator 96 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
